1FK7060-2AF71-1CG0-ZQ31 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1CG0-ZQ31 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIMOTICS S motor with the product code 1FK7060-2AF71-1CG0-ZQ31 is part of the well-established SIEMENS 1FK7 series, engineered to deliver reliable and precise performance for modern automated machinery. With a rated power of 1.5 kW, natural cooling, and a nominal speed of 3000 rpm, this motor supports highly dynamic operation while maintaining stable torque characteristics. Its compact dimensions allow easy integration into machines where efficiency and reduced installation space are critical. A robust design with IP64 protection ensures consistent performance even in demanding industrial environments.

This motor configuration includes a smooth shaft, rotatable power connector, and a high-resolution absolute encoder featuring both 24-bit and 12-bit multiturn technology via DRIVE-CLiQ. This advanced feedback system enables accurate speed and position control, making it suitable for complex motion applications. The motor operates without a holding brake, which further contributes to low inertia and high responsiveness. The metallic rating plate identified by option Q31 provides enhanced durability for identification in harsh conditions.

Overview

Motors within the SIMOTICS S-1FK7 family are known for their compact structure, wide configuration range, and compatibility with SINAMICS S120 and S220 drive platforms. These motors support permanent-magnet technology, delivering strong dynamic behavior, high power density, and flexible encoder options. Their ability to dissipate heat through the motor housing allows operation without external cooling devices, improving system efficiency and reducing installation complexity.

Benefits

• Space-saving design with excellent power density
• Wide selection of configurations for universal use
• High dynamic response thanks to low rotor inertia
• Stable closed-loop performance for variable load conditions
• Reduced commissioning effort due to precise encoder feedback

Application

• Machine tools and precision machinery
• Robotic systems and automated handling units
• Wood, glass, stone, and ceramic processing machines
• Packaging, plastics, and textile equipment
• Printing and auxiliary axes for integrated systems

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1CG0-ZQ31
