1FK7060-2AF71-1CG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,097.81
The SIEMENS 1FK7060-2AF71-1CG2 is a compact SIMOTICS S-1FK7 synchronous motor offering precise performance, high overload capability and reliable closed-loop control for advanced industrial machinery.
1FK7060-2AF71-1CG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7060-2AF71-1CG2 is a high-performance synchronous motor engineered for demanding industrial applications that require precision, stability and long-term reliability. Belonging to the renowned SIMOTICS S-1FK7 series, this compact motor delivers a rated power of 1.5 kW, a torque capability of 6 Nm, and a nominal speed of 3000 rpm. It is designed for natural cooling, allowing heat dissipation through the motor housing, which ensures consistent performance even under extended operating cycles. With its IP65 front protection and IP67 flange rating, the motor is suitable for challenging industrial environments where durability is essential.
The model features a rotatable power connector, a smooth shaft with tolerance class N, and no holding brake to support flexible integration into machine designs. Equipped with a high-resolution 24-bit absolute encoder and 12-bit multiturn function using the DRIVE-CLiQ interface, it provides accurate feedback for advanced closed-loop motion systems. This combination enhances positioning precision and speed control while reducing commissioning complexity for engineers working with modern automation architectures.
Overview
The SIMOTICS S-1FK7 family is known for its adaptability, compact construction and ability to meet increasing performance requirements in next-generation machinery. These motors integrate seamlessly with SINAMICS S120 or S220 drive systems to create a unified, high-functionality motion platform. Their broad range of options—from encoder types to mechanical variations—allows optimal configuration for a diverse set of applications. With high overload capability and robust behavior under dynamic load conditions, the series is a preferred choice for machine builders worldwide.
Benefits
- Compact design for installations with limited space
- Versatile performance suitable for universal industrial use
- High-dynamic variants with extremely low rotor inertia
- Stable operation for applications with fluctuating load torque
- Minimal tuning requirements due to strong closed-loop behavior
Application
- Machine tools and precision machining systems
- Robotics, handling equipment and automated assembly lines
- Wood, glass, ceramics and stone processing machinery
- Packaging, plastics and textile production systems
- Printing technologies and auxiliary motion axes
Download
Product Code:1FK7060-2AF71-1CG2
More Siemens products at Turll.com.
| Weight | 7.101 kg |
|---|
