1FK7060-2AF71-1CH1-ZJ17 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$5,928.91
The SIEMENS SIMOTICS S 1FK7060-2AF71-1CH1-ZJ17 motor delivers high efficiency, precise control, and smooth dynamic behavior through advanced encoder technology and durable mechanical construction.
1FK7060-2AF71-1CH1-ZJ17 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S motor with product code 1FK7060-2AF71-1CH1-ZJ17 is engineered for demanding automation environments where precision, efficiency, and long-term reliability are essential. This high-performance unit belongs to the advanced 1FK7-CT family, offering 1.5 kW rated power, a 600 V DC link voltage, a stall torque foundation of 6 Nm, and a nominal speed of 3000 rpm. Designed with a naturally cooled IMB 5 construction, the motor provides exceptional thermal performance while maintaining a compact footprint, making it suitable for a broad range of modern machine applications.
This model integrates a 24-bit plus 12-bit multiturn absolute encoder that communicates through the DRIVE-CLiQ interface. With accurate feedback and optimized speed control, it enables smooth operation even under rapidly changing loads. The rotatable power connector, durable IP65 protection, holding brake, and smooth shaft design ensure compatibility with a variety of mechanical interfaces. Additionally, the ZJ17 configuration includes an ALPHA SP+ planetary gearbox with a 50:1 reduction ratio, delivering reliable torque conversion and outstanding transmission accuracy for high-precision positioning tasks.
Overview
The SIMOTICS S-1FK7 series is widely regarded for its compact structure, high power density, and adaptability. The extensive range of mechanical and encoder options ensures suitability for both simple and highly dynamic machine functions. When paired with SINAMICS S120 or S220 drive systems, the motor becomes part of a fully integrated servo solution that supports advanced motion requirements with exceptional performance stability.
Benefits
- Compact size enabling flexible installation
- High thermal capability and robust overload margin
- Dynamic response for applications requiring fast acceleration
- Stable closed-loop control for systems with fluctuating inertia
- Reduced commissioning time through optimized encoder technology
Application
- Machine tool automation
- Robotic handling systems
- Woodworking, glass, ceramic, and stone processing
- Textile, packaging, and plastic machinery
- Printing and auxiliary motion axes
Download
Product Code: 1FK7060-2AF71-1CH1-ZJ17
More Siemens products at Turll.com.
| Weight | 24.4 kg |
|---|
