1FK7060-2AF71-1FA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1FA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S motor with model number 1FK7060-2AF71-1FA2 is engineered for advanced automation performance, offering a balanced combination of efficiency, precision, and reliability. Designed as part of the SIMOTICS S-1FK7 series, this compact synchronous motor delivers a rated power of 1.5 kW with a torque value of 6 Nm at 3000 rpm. Its naturally cooled design and IMB5 mounting configuration make it an excellent choice for integration into modern machine concepts where high functionality and minimal maintenance requirements are essential.

This motor is equipped with a high-resolution absolute encoder AM22DQ featuring 22-bit single-turn and 12-bit multi-turn capability. The integrated DRIVE-CLiQ interface ensures seamless interaction with SINAMICS drives, enabling accurate feedback and stable closed-loop operation. A rotatable power connector adds installation flexibility, while a shaft with fitted key contributes to a secure and dependable mechanical connection. The device operates without a holding brake and is built to withstand demanding industrial environments with IP65 protection for the housing and IP67 protection at the flange.

Overview

The SIMOTICS S-1FK7 family is known for its compact construction, expanded motor range, and compatibility with a wide spectrum of mechanical and automation applications. These motors support universal deployment thanks to their high power density and broad encoder and gearbox options. When paired with SINAMICS S120 or S220 drives, they form a highly capable motion control system suitable for precise speed and position-regulated tasks.

Benefits

• High power density for compact installations
• Versatile motor range for various industrial needs
• Excellent dynamic response in applications requiring rapid acceleration
• Robust control behavior for machines with fluctuating load inertia
• Minimal commissioning effort, even with complex disturbances

Application

The motor is suitable for machine tools, advanced robotics, packaging systems, material processing machines, printing machinery, and numerous auxiliary axes found in precision-driven production environments. Its combination of performance and adaptability ensures long-term operational value in both high-speed and high-stability applications.

Product Code:
1FK7060-2AF71-1FA2
