1FK7060-2AF71-1FB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1FB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S motor in this configuration delivers a high-performance motion solution tailored for demanding industrial environments. Designed for precise control, stable torque output, and long-term reliability, this premium synchronous motor supports a power rating of 1.5 kW with a nominal speed of 3000 rpm. Its compact, naturally cooled design ensures efficient thermal dissipation through the motor surface, making it suitable for continuous operation in a wide range of automation systems. The integrated AM22DQ encoder, combining 22-bit resolution with a 12-bit multiturn system, enables highly accurate feedback for both speed and position control. With a fitted-key shaft, Drive-CLiQ interface, rotatable power connector, and IP64 protection, the device meets modern machine-building standards where precision, durability, and safe operation are essential.

This motor includes a holding brake and is optimized for IMB 5 mounting, offering compatibility with vertical or horizontal installations. Engineered with robustness in mind, it performs effectively under variable loads, supporting a wide variety of industrial applications such as machining centers, automated production lines, and robotic systems. The motor’s high overload capacity ensures stable operation even during intensive duty cycles or dynamic load changes.

Overview

The SIMOTICS S-1FK7 1FK7060-2AF71-1FB0 family is known for its compact synchronous design, high power density, and modular selection range. Options such as multiple encoder types, gear units, and mechanical variants allow seamless adaptation to system requirements. When paired with SINAMICS S120 or S220 drives, the motor forms an advanced motion platform suitable for automation architectures requiring precision and responsiveness.

Benefits

• Compact construction for space-optimized installation
• High-dynamic variants for systems requiring rapid acceleration
• High-inertia versions for stable closed-loop control
• Minimal commissioning effort thanks to integrated encoder systems
• Wide selection of mechanical and electrical configurations

Application

• Machine tools and high-precision cutting systems
• Robotics, automated handling, and assembly systems
• Wood, glass, stone, and material-processing equipment
• Packaging, textile, and plastics machinery
• Printing and auxiliary industrial axes

Product Code:1FK7060-2AF71-1FB0
