1FK7060-2AF71-1QG1-ZJ22 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1QG1-ZJ22 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AF71-1QG1-ZJ22 is a high-performance synchronous motor engineered to deliver precision, durability, and consistent output for a broad range of industrial applications. As part of the SIMOTICS S-1FK7 series, this model combines compact construction with exceptional efficiency, making it suitable for modern machine designs where reliable torque and rapid response are essential. Designed with a naturally cooled body, the motor efficiently dissipates heat through its surface, ensuring steady operation even in demanding environments. Its 1.5 kW power rating, 6 Nm torque, and 3000 rpm speed capability support both continuous and dynamic motion requirements.

This motor variant integrates a single-turn 20-bit absolute encoder with Drive-CLiQ interface, enabling accurate feedback for high-precision control tasks. The rotatable power connector and IMB 5 mounting compatibility offer straightforward installation across various machine configurations. Equipped with a smooth shaft and IP65 protection, the motor is built to withstand exposure to dust and water, reinforcing its robustness for long-term industrial deployment.

An important highlight of the 1FK7060-2AF71-1QG1-ZJ22 is the inclusion of the ALPHA SP+ SP 100S-MF1 planetary gearbox, featuring a 1-stage reduction ratio of 10. This configuration extends torque capabilities while maintaining consistent motion control, making the unit suitable for applications involving sudden load variations or precise positioning. The combined motor-gearbox system enables mechanical efficiency and stability across a wide performance spectrum, allowing engineers to implement it seamlessly in automation, robotics, packaging machinery, and specialized manufacturing systems.

Overview

The SIMOTICS S-1FK7 series offers a wide selection of compact permanent-magnet synchronous motors. With adaptable encoder options, gearbox integration, and an extended product range, the motors can be configured to match a variety of machine requirements. When paired with SINAMICS S120 or S220 drive systems, they form a high-functionality drive platform with strong performance characteristics.

• High power density for space-efficient installation
• Broad portfolio tailored for universal industrial use
• High Dynamic variants for reduced rotor inertia and rapid response
• High Inertia variants for stable closed-loop control
• Minimal tuning effort even when load inertia varies

Applications

• Machine tools
• Robotics and automated handling
• Wood, glass, stone, and material processing
• Packaging, plastics, and textile equipment
• Printing and auxiliary axis systems

Download

Data Sheet (PDF)

Product Code:
1FK7060-2AF71-1QG1-ZJ22
