1FK7060-2AF71-1RG1-ZJ25 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

1FK7060-2AF71-1RG1-ZJ25 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

The 1FK7060-2AF71-1RG1-ZJ25 SIMOTICS S-1FK7 is a high-performance synchronous motor engineered for demanding industrial applications. Delivering a nominal power of 1.5 kW and a rated speed of 3000 rpm, this motor ensures smooth and precise operation with a torque of 6 Nm. It features a naturally cooled design, eliminating the need for external cooling, and is built according to IMB 5 mounting standards. The motor incorporates a rotatable power connector and an advanced absolute encoder system with 20-bit single-turn and 12-bit multiturn capability via the DRIVE-CLiQ interface (encoder AM20DQI), providing accurate position and speed feedback for sophisticated automation tasks.

Overview

The SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors optimized for a wide range of machinery and automation solutions. They are designed to integrate seamlessly with the SINAMICS S120/S220 drive systems, forming a highly functional and versatile motion control solution. Thanks to their integrated encoder systems, these motors allow precise closed-loop control and can be adapted to specific application requirements. The smooth shaft design, tolerance N, IP65 degree of protection, and planetary gearing option J25: ALPHA SP+, SP 100S-MF1 stage with I=7 ensure reliability under challenging operating conditions.

Benefits

• Space-saving installation due to high power density
• Universal application suitability across multiple industries
• Variety of motor types to meet dynamic or high-inertia requirements
• Exceptional dynamic response for high-speed applications
• Robust control for varying load inertia
• Minimal commissioning effort and easy integration into machine systems

Applications

These motors are suitable for a wide array of industrial sectors, including machine tools, robotic and handling systems, wood, glass, ceramics, and stone processing, as well as packaging, plastics, textiles, and printing machines. They are ideal for auxiliary axes and any system requiring high precision and reliable performance.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1RG1-ZJ25
