1FK7060-2AH71-1BB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AH71-1BB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AH71-1BB2 is a high-performance synchronous motor engineered to deliver exceptional efficiency, precision, and dynamic motion control in advanced automation environments. Built as part of the SIMOTICS S-1FK7 series, this model offers reliable torque output of 6 Nm, a nominal speed of 4500 rpm, and a robust structural design optimized for demanding industrial tasks. With a naturally cooled IMB 5 construction and a rotatable power connector, it provides excellent adaptability for numerous installation scenarios. This motor integrates a 24-bit single-turn absolute encoder with DRIVE-CLiQ interface, enabling extremely accurate position feedback and ensuring smooth operation within high-accuracy motion applications.

Its rugged mechanical configuration includes a shaft with feather key, a holding brake option, and an enclosure that achieves IP65 protection at the drive end and IP67 protection at the flange. These characteristics make the motor suitable for continuous use in challenging environments where durability, stability, and long service life are required. Designed for seamless integration into SINAMICS S120 or S220 drive systems, the motor contributes to a powerful, fully harmonized motion platform with advanced control capabilities. The surface-cooled design also supports high thermal efficiency, allowing the motor to sustain overload conditions while maintaining consistent performance.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous units designed for universal industrial applications. Their modular options—such as encoder variants, mechanical interfaces, and compatible gear units—allow system builders to match the motor configuration precisely to operational needs. These motors deliver dependable speed and position control while offering an expanded performance range suitable for new machine generations.

Benefits

• Compact design enabling space-efficient installation with excellent power density.
• Wide application flexibility across diverse machine types.
• High dynamic response with low rotor inertia options.
• Stable closed-loop behavior for varying load conditions.
• Minimal tuning effort and simplified commissioning.

Application

Typical uses include metalworking machines, automated robots, assembly and handling systems, woodworking equipment, glass and stone processing lines, packaging technology, textile production, and auxiliary motion axes in complex machinery.

Download

Data Sheet (PDF)

Product Code:
1FK7060-2AH71-1BB2
