High-precision SIEMENS SIMOTICS S synchronous motor delivering compact design, excellent dynamics, advanced encoder technology, and reliable performance for modern automation tasks.
The SIEMENS 1FK7060-2AH71-1DA2 belongs to the SIMOTICS S-1FK7 series, a renowned family of high-performance synchronous motors created for precision, reliability and adaptability across a wide range of industrial environments. Built with a compact footprint and engineered for excellent mechanical strength, this motor delivers consistent torque and stable behavior even under demanding operating conditions. Featuring a rated power of 1.7 kW, a torque class of 6 Nm at 100K, and a nominal speed of 4500 rpm, it supports efficient performance in fast-cycling and continuous-duty applications. Natural cooling through its outer surface ensures dependable thermal stability without the need for auxiliary cooling systems.
1FK7060-2AH71-1DA2 Equipped with a rotatable power connector and an advanced 22-bit incremental encoder with DRIVE-CLIQ interface, the motor enables precise position and speed feedback. This enhances the accuracy of motion control and allows seamless integration with compatible drive systems. Its IP65 degree of protection, with IP67 at the drive-end flange, ensures robust resistance to dust and water exposure. The fitted-key shaft with standard tolerances supports reliable mechanical coupling, and the absence of a holding brake makes it suitable for systems where free rotation is required.
SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors created for flexible adaptation to modern machinery. A wide selection of encoders and mechanical options enables configuration for numerous applications and performance profiles. When combined with SINAMICS S120 or S220 drive systems, they form an efficient automation platform with high-precision control and expanded functional capabilities. Their optimized thermal design ensures long-term durability and strong overload performance.
These motors offer a space-efficient design with high power density, making them suitable for universal use across many machine types. The Compact, High Dynamic, and High Inertia variants cover a broad spectrum of performance requirements—from rapid motion sequences to stable operation with heavy load variations. Reduced commissioning effort and strong disturbance compensation further contribute to easier integration.
Typical uses include machine tools, robotics, handling systems, packaging machinery, printing equipment, and various production technologies for materials such as wood, glass, ceramics, and plastics. Their reliability and configurable nature make them an excellent choice for both new installations and modernization projects.
Product Code: 1FK7060-2AH71-1DA2
More Siemens products at Turll.com
| SKU / Model | 1FK7060-2AH71-1DA2 |
|---|---|
| Weight | 7.102 kg |
