1FK7060-2AH71-1QB1 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

1FK7060-2AH71-1QB1 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

The SIEMENS 1FK7060-2AH71-1QB1 SIMOTICS S-1FK7 motor is a high-performance synchronous motor designed for precision industrial applications. Delivering 1.7 kW of power and a nominal torque of 6 Nm at 4500 rpm, this motor integrates a compact permanent-magnet design with naturally cooled construction, ensuring efficient thermal management without the need for external cooling systems. Its IMB 5 (IM V1, IM V3) flange and rotatable power connector provide flexible installation options. Equipped with a single-turn 20-bit absolute encoder featuring the DRIVE-CLiQ interface (AS20DQI), the motor allows precise speed and position feedback for advanced motion control systems. The shaft with feather key and N-tolerance, along with an integrated holding brake and IP65 protection rating, ensures durability even in challenging industrial environments.

The SIMOTICS S-1FK7 series offers a wide range of motor variants, allowing seamless adaptation to machine-specific requirements. Compact motors provide high power density and space-saving installation, making them ideal for universal applications across robotics, machine tools, and material handling systems. High Dynamic variants deliver extremely fast response times thanks to low rotor inertia, while High Inertia variants ensure robust performance under variable or high load conditions. These motors integrate easily with the SINAMICS S120/S220 drive systems to create a high-functionality, fully coordinated automation solution.

Designed for minimal commissioning effort, the 1FK7060-2AH71-1QB1 offers efficient disturbance compensation and long-term reliability. Its application versatility spans packaging machinery, plastics and textile processing, wood, glass, ceramics, stone working, and auxiliary axes in advanced printing machines. With a focus on precision, robustness, and adaptability, this motor ensures exceptional performance while maintaining compact installation space and high efficiency, meeting the evolving requirements of modern industrial systems.

Overview

SIMOTICS S‑1FK7 motors are compact permanent-magnet synchronous motors with extensive options for encoders and gearboxes. They are engineered to meet the increasing performance and precision demands of state-of-the-art machine generations. Integrated encoder systems provide accurate speed and position control, tailored to the application. The motors dissipate heat through the surface, eliminating the need for external cooling, and provide high overload capability for demanding operational conditions.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AH71-1QB1
