1FK7060-2AH71-1QH1-ZJ09 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

1FK7060-2AH71-1QH1-ZJ09 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

The SIMOTICS S-1FK7 is a high-performance synchronous motor engineered for demanding industrial applications. With a rated power of 1.7 kW, a nominal voltage of 600 V, and a nominal torque of 6 Nm, this motor delivers exceptional precision and reliability. The naturally cooled design with IMB 5 construction ensures efficient heat dissipation, making it suitable for continuous operation without external cooling systems. Equipped with a single-turn 20-bit absolute encoder (AS20DQI) featuring the DRIVE-CLiQ interface, this motor enables precise speed and position control, ideal for integration with SINAMICS S120/S220 drive systems.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to meet the evolving demands of modern machinery. Their modular design allows for flexible adaptation through various encoder options and gearboxes, including planetary gearing (J09: ALPHA SP+, SP 100S-MF1, 1 stage, I=10) with feather key, providing smooth and efficient torque transmission. The motors offer high overload capacity and minimal maintenance requirements, ensuring long-term reliability even in high-demand production environments. Compact dimensions and high power density allow space-saving installation without compromising performance.

Benefits

• Compact design enabling installation in tight spaces
• High dynamic response with low rotor inertia for precision tasks
• Robust closed-loop control for applications with high or varying load inertia
• Wide range of motor variants for universal use in multiple industries
• Minimal setup and commissioning efforts required for operation

Applications

The motor is ideally suited for:

• Machine tools
• Robots and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machines
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AH71-1QH1-ZJ09
