1FK7060-2AH71-1UA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AH71-1UA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AH71-1UA1 is a precision-engineered synchronous motor from the renowned SIMOTICS S-1FK7 series, designed to deliver exceptional reliability and performance for a broad range of industrial applications. Built with a permanent-magnet rotor, this model provides consistent torque output, smooth rotational characteristics, and stable operation even under demanding load conditions. Its naturally cooled IMB5 construction ensures efficient heat dissipation through the motor surface, making the motor well-suited for continuous duty environments without the need for additional cooling equipment. The 1.7 kW rated power, 6 Nm standstill torque, and high-speed capability of 4500 rpm allow it to support precise, dynamic movement within complex automation systems.

Equipped with a multi-pole resolver and DRIVE-CLiQ interface, the motor enables accurate position and speed feedback, ensuring seamless integration with advanced drive platforms. The rotatable power connector and shaft with feather key support flexible installation, while the IP65 protection class enhances durability in harsh environments. Compact construction also allows space-saving integration into machines with limited mounting areas.

Overview

SIMOTICS S-1FK7 motors are compact synchronous units designed to deliver high performance across a wide range of operational settings. This motor family supports a variety of encoders and mechanical options, allowing tailored configuration for numerous industrial processes. When paired with SINAMICS S120 or S220 drive systems, the motors create a highly efficient, function-rich motion control solution suitable for precision-driven machinery.

• Compact design with high power density
• Available in multiple variants for universal applications
• Supports dynamic to high-inertia load conditions
• Operation without external cooling systems
• High overload capability for challenging tasks

Benefits

• Flexible adaptation through wide motor selection and encoder options
• Stable control behavior for variable load conditions
• Reduced commissioning time and disturbance compensation
• High responsiveness for advanced automation tasks

Application

• Machine tools
• Robotic and automated handling systems
• Wood, glass, stone and material processing
• Packaging and textile machinery
• Printing equipment and auxiliary drive axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AH71-1UA1 —
View Siemens Product Page
