1FK7061-4CH71-1CB1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1CB1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1CB1 SIMOTICS S motor is a high-performance synchronous motor designed for precision motion tasks across modern industrial environments. With a rated power of 2 kW, a nominal torque of 6.4 Nm, and a maximum speed of 4500 rpm, this motor supports dynamic acceleration and stable performance even during frequent load variations. The permanently excited design ensures excellent efficiency, while the natural cooling configuration delivers sustained thermal stability without requiring external cooling units.

Equipped with a rotatable power connector and a robust mechanical structure built around IMB 5 mounting, this motor simplifies installation for machine builders and integrators. The fitted key shaft with tolerance class N ensures optimal mechanical compatibility, and the integrated holding brake enhances operational reliability during static positioning and emergency stops. Its 24-bit + 12-bit multiturn absolute encoder with DRIVE-CLiQ interface (AM24DQI) provides high-resolution feedback, supporting advanced positioning accuracy in demanding automation systems.

Overview

SIMOTICS S-1FK7 motors are compact synchronous motors engineered for flexible applications requiring a balance of dynamic response, precision, and long-term durability. Their modular range of options, including encoder variations, gear interfaces, and mechanical designs, allows them to be configured to suit a wide variety of automated systems. When combined with SINAMICS S120 or S220 drive systems, they create a seamless motion control platform with efficient closed-loop performance.

Developed for operation without external cooling, these motors dissipate heat through their surfaces, enabling high overload capability and maintaining consistent thermal behavior during continuous operation.

Design & Key Features

• Permanent-magnet synchronous motor with high power density
• 24-bit + 12-bit multiturn absolute encoder AM24DQI with DRIVE-CLiQ
• Natural cooling for stable thermal performance
• High dynamic response suited for fast acceleration
• Holding brake for secure static positioning
• IP65 protection for industrial environments
• IMB 5 construction with flange design for easy installation

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1CB1
