1FK7061-4CH71-1FG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,253.08
High-performance SIEMENS SIMOTICS S 1FK7061-4CH71-1FG2 synchronous motor designed for precision control, featuring multiturn encoder technology and durable construction.
1FK7061-4CH71-1FG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7061-4CH71-1FG2 is a highly capable synchronous motor designed to deliver precise motion control and exceptional consistency in demanding industrial environments. As part of the advanced SIMOTICS S-1FK7 High Dynamic series, this motor provides excellent performance through its permanent-magnet construction, optimized torque response, and stable speed characteristics. With a power rating of 2 kW, a nominal torque of 6.4 Nm, and a maximum speed of 4500 rpm, it is built to support applications requiring fast acceleration and smooth motion profiles. The naturally cooled design improves thermal behavior, while the robust IP65/IP67 protection level enhances reliability in challenging operating conditions.
This motor version features a 22-bit + 12-bit multiturn absolute encoder with DRIVE-CLiQ interface, delivering reliable feedback for precision motion tasks. Its plain shaft with tolerance class N ensures compatibility with numerous mechanical configurations, and the rotatable power connector simplifies installation within compact machine layouts. The absence of a holding brake reduces mechanical complexity in systems where braking is managed externally or not required.
Overview
SIMOTICS S-1FK7 motors are engineered as compact synchronous motors for a wide range of automation requirements. Their broad range of variants, including encoder options and mounting configurations, allows seamless integration into machine tools, robotics, and general automation systems. These motors pair effectively with SINAMICS S120 or S220 drive systems, delivering a high-performance motion platform with advanced control features.
With strong overload capability, consistent heat dissipation, and stable dynamic response, the 1FK7 series ensures reliable operation even in fast-paced or demanding production environments.
Design & Key Features
- High-dynamic permanent-magnet synchronous motor
- 22-bit + 12-bit multiturn encoder with DRIVE-CLiQ interface
- Rotatable power connector for flexible cabling
- Plain shaft design, tolerance class N
- Robust housing with IP65/IP67 protection
- Optimized for natural cooling operation
- IMB 5 mounting with flange type 1
Product Code: 1FK7061-4CH71-1FG2
More Siemens products at Turll.com
| Weight | 9.501 kg |
|---|
