1FK7061-4CH71-1RH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,045.06
High-performance SIEMENS SIMOTICS S 1FK7061-4CH71-1RH1 synchronous motor featuring multiturn encoder technology, strong torque output, and durable IP65 construction.
1FK7061-4CH71-1RH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7061-4CH71-1RH1 SIMOTICS S motor is a high-quality synchronous motor engineered to deliver accurate, stable, and highly responsive performance across a wide range of industrial environments. As part of the SIMOTICS S-1FK7 High Dynamic series, this model offers a strong balance of torque, efficiency, and reliability. With a nominal torque rating of 6.4 Nm and a speed capability of 4500 rpm, it supports demanding operational tasks while maintaining consistent thermal performance through its natural cooling system. The rugged IMB 5 construction simplifies integration, and the flange configuration provides dependable mechanical stability.
This variant includes a 20-bit + 12-bit multiturn absolute encoder (AM20DQI) with DRIVE-CLiQ communication, providing high-resolution feedback for advanced motion control applications. The plain shaft offers a smooth mechanical interface, and the motor includes a reliable holding brake for secure positioning during system stops. With an IP65 protection level, the unit is built to withstand challenging industrial conditions, including dust and water exposure, ensuring long-term operational endurance.
Overview
SIMOTICS S-1FK7 motors are compact synchronous motors designed for flexibility and optimized performance. Their wide variety of configurations, optional gear units, and encoder technologies enable perfect adaptation for different machine concepts. When paired with SIEMENS SINAMICS S120 or S220 drive systems, they form a powerful and feature-rich motion control platform capable of delivering accurate speed control, smooth positioning, and high dynamic response.
These motors are designed for applications requiring reliable operation without external cooling. Heat is effectively dissipated through the motor housing, supporting stable continuous operation. High overload capability further enhances performance during acceleration and rapid cyclic movement.
Design & Key Features
- Advanced permanent-magnet synchronous motor construction
- High-resolution AM20DQI absolute multiturn encoder with DRIVE-CLiQ interface
- Durable plain shaft, tolerance class N
- Holding brake for secure static positioning
- Compact design with high power density
- Protection class IP65 for reliable operation in harsh environments
- Optimized for versatile automation and precision motion systems
Download
Product Code: 1FK7061-4CH71-1RH1
More Siemens products at Turll.com
| Weight | 9.8 kg |
|---|
