1FK7062-2AC71-1CG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,127.58
High-precision SIEMENS SIMOTICS S 1FK7062-2AC71-1CG0 motor with multiturn encoder, natural cooling, and reliable performance for advanced automation environments.
1FK7062-2AC71-1CG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The 1FK7062-2AC71-1CG0 SIMOTICS S synchronous motor from SIEMENS is engineered to deliver reliable and precise performance across a wide range of advanced industrial automation environments. Developed as part of the renowned 1FK7-CT series, this unit offers exceptional stability and energy efficiency, making it a powerful choice for machine builders requiring consistent torque output and refined motion control. With a nominal torque of 8.5 Nm, 1.5 kW power rating, and a speed of 2000 rpm, it provides balanced performance for demanding systems that rely on accuracy and smooth operation.
Designed with a naturally cooled structure, this motor dissipates heat effectively through its external surface, allowing dependable operation without the need for supplemental cooling. The smooth shaft with tolerance class N enhances mechanical compatibility, particularly for precision-driven processes. Its protection level of IP64 supports operation in environments where exposure to dust or splashes may occur, contributing to dependable long-term functionality.
The integrated AM24DQI absolute encoder system combines 24-bit single-turn and 12-bit multiturn resolution, enabling highly accurate feedback for speed and position control. The inclusion of a rotatable power connector further simplifies installation, offering flexibility during machine integration. With IMB 5 mechanical construction and a universal flange design, the motor adapts effortlessly to a variety of industrial configurations.
Overview
SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to meet the evolving requirements of modern machinery. Their wide range of options, including multiple encoder types and adaptable mechanical variants, ensures they can be integrated into highly specialized automation systems. When paired with SINAMICS S120 or S220 drive systems, they offer advanced performance with exceptional control precision.
These motors feature strong thermal behavior, high overload capability, and robust dynamic response, making them suitable for industries that demand continuous reliability and accurate operation.
Design & Key Features
- Absolute encoder AM24DQI with 24-bit + 12-bit multiturn resolution
- Rotatable power connector for simplified installation
- Smooth shaft, tolerance class N
- Protection rating IP64 suitable for industrial environments
- IMB 5 construction with universal flange design
- High overload capability and natural cooling concept
- Optimized for SINAMICS S120/S220 drive systems
Download
Product Code: 1FK7062-2AC71-1CG0
More Siemens products at Turll.com
| Weight | 9.101 kg |
|---|
