1FK7062-2AF71-1BG2 SIEMENS Exclusive Synchronous Motor Original Brand New

1FK7062-2AF71-1BG2 SIEMENS Exclusive Synchronous Motor Original Brand New

The 1FK7062-2AF71-1BG2 SIEMENS synchronous motor is a high-performance member of the SIMOTICS S-1FK7 series, designed for precise motion control in demanding industrial environments. With a rated power of 1.9 kW and a DC link voltage of 600 V, this motor delivers reliable torque and consistent operation at speeds up to 3000 rpm. The naturally cooled design allows heat to dissipate efficiently, eliminating the need for external cooling while maintaining stable performance under continuous duty.

Its IMB 5 (IM V1, IM V3) flange design ensures compatibility with a variety of mechanical systems, while the rotatable power connector enhances flexibility during installation. The integrated single-turn 24-bit absolute encoder (AS24DQI) with DRIVE-CLiQ interface provides precise position feedback, making the motor ideal for applications requiring exact control. The smooth shaft with tolerance N, degree of protection IP65 on the drive end and IP67 on the flange, further reinforces the durability and robustness of this motor.

The 1FK7062-2AF71-1BG2 can be seamlessly integrated with the SINAMICS S120/S220 drive systems to form a complete, high-performance motion solution. Its compact permanent-magnet construction allows for space-saving installation without compromising power density. High dynamic response and closed-loop control stability make this motor suitable for tasks with varying load inertia, while minimal commissioning overhead simplifies setup and reduces operational downtime.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous units designed for a wide range of industrial applications. Their modular design, including options for gearboxes and encoders, allows for precise adaptation to individual machine requirements. These motors satisfy the increasing demands of modern automated machinery, delivering high efficiency, reliability, and consistent performance.

Key Features

• High power density for space-saving installation
• Reliable performance under continuous operation
• Integrated absolute encoder for precise positioning
• Flexible mechanical integration with rotatable connectors
• Robust construction suitable for harsh industrial environments

Applications

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing machines
• Auxiliary axes in industrial equipment

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AF71-1BG2
