6AG2243-5DX30-1XE0 Siemens SIPLUS S7-1200 CM 1243-5 T1 Rail Original Brand New
$2,208.55
6AG2243-5DX30-1XE0
Siemens SIPLUS S7-1200 CM 1243-5 T1 rail based on 6GK7243-5DX30-0XE0 with conformal coating, -25…+55 °C, OT1 with ST1/2 (+70 °C für 10 minutes), communications module CM 1243-5 for connecting S7-1200 to PROFIBUS as DP master module
[ez-toc]
Overview
The SIPLUS S7-1200 CM 1243-5 RAIL communications module is used to connect a SIPLUS extreme RAIL S7-1200 to PROFIBUS as a DP master and has the following characteristics:
- Approved in accordance with the railway standards EN 50155, EN 15121, EN 50124, EN 50125 and EN 45545 for use in rail traffic
- PROFIBUS DPV1 master in accordance with IEC 61158
- Support of up to 16 PROFIBUS DP devices
- Communication with other S7 controllers based on S7 communication
- Allows the connection of programming devices and operator panels with a PROFIBUS interface to the S7-1200
- Module replacement without PG supported
- Support of all standard baud rates from 9.6 Kbps to 12 Mbps
- Compact industry-standard enclosure in S7-1200 design for mounting on a DIN rail
- Fast commissioning thanks to easy configuration using STEP 7 without additional programming overhead
The SIPLUS S7-1200 CM 1243-5 RAIL is intended for use in rail traffic. Low-cost PROFIBUS-based automation solutions can be created on the basis of the S7-1200 for optimal production.
Benefits
PROFIBUS-based systems can be operated effectively for lower operating and maintenance costs:
- Low costs since an automation solution requires no fixed wiring and less hardware
- Fast response to faults thanks to excellent diagnostics options
- Optimized plant and inventory management
The SIPLUS S7-1200 CM 1243-5 RAIL also offers further benefits especially for the requirements of micro-automation solutions:
- Uncomplicated connection of the S7-1200 to PROFIBUS
- Low-cost implementation of automation solutions based on PROFIBUS
- Fast commissioning, as no programming overhead is required
Use of PROFIBUS-based micro-automation solutions enables optimal operation of the plant.
Application
The SIPLUS S7-1200 CM 1243-5 RAIL is designed for use in rail traffic.
With the CM 1243-5 RAIL, low-cost, distributed automation solutions can be implemented on the basis of the S7-1200, or in simple cases even complete plant automation systems. It can be used in all sectors of discrete automation.
Design
The SIPLUS S7-1200 CM 1243-5 RAIL offers all the benefits of the S7-1200 design.
- Rugged, compact plastic enclosure
- Easily accessible connection and diagnostics elements, protected by front flaps
- Removable terminals
- Simple mounting on the mounting rail of the S7-1200
- 9-pin sub-D socket for the bus interface to PROFIBUS
- 3-pin plug-in terminal strip for connection of the 24 V DC external supply voltage
The CM 1243-5 RAIL is plugged into the left-hand system bus interface of the S7-1200. The power is supplied via a 3-pin terminal strip on top of the module. The rugged RS485 interface is located on the underside of the module, protected by the lower front flap.
Function
The SIPLUS S7-1200 CM 1243-5 RAIL provides access to different communications services on the basis of PROFIBUS:
- PROFIBUS DP (according to IEC 61158, master)
- PG/OP communication
- S7 communication
PROFIBUS DP master
The CM 1243-5 RAIL works as a DP-V1 master in accordance with IEC 61158, handles data traffic completely autonomously, and thus relieves the CPU of communication tasks.
The data areas of the distributed I/Os are transferred consistently between CP and CPU. As a DP master, it allows the connection of up to 16 PROFIBUS-compliant DP devices.
PG/OP communication
The S7-1200 to which the CM 1243-5 RAIL is connected can be programmed with the help of PG/OP communication.
S7 communication
Communication with the following other systems can be implemented with the mechanisms familiar from the S7 world (Put/Get) on the basis of S7 communication:
- To other SIMATIC S7 programmable controllers
- To HMI devices
- To PCs, laptops, field PGs with PROFIBUS cards
Diagnostics
Extensive diagnostic options are available via STEP 7, including
- Operating status of the CM
- General diagnostics and statistics functions
- Connection diagnostics
- Alarm buffer
STEP 7 Basic is required for configuring the full functional scope of the CM 1243-5 RAIL.
6AG2243-5DX30-1XE0
Siemens SIPLUS S7-1200 CM 1243-5 T1 rail based on 6GK7243-5DX30-0XE0 with conformal coating, -25…+55 °C, OT1 with ST1/2 (+70 °C für 10 minutes), communications module CM 1243-5 for connecting S7-1200 to PROFIBUS as DP master module
Visit 6AG2243-5DX30-1XE0
For more our products visit turll.com
| Weight | 0.196 kg |
|---|---|
| Dimensions | 91 × 109 × 56 mm |
