Overview
SIMATIC Visualization Architect (SiVArc)
Challenge:
- To standardize the user interfaces of the visualizations throughout the plant
- Significant reduction of the engineering costs for generating the visualizations
- To make the in-house work standard usable
Solution:
- Automatic generation and creation of the visualizations, based on the program code of the PLC and corresponding visualization objects within the framework of system-wide library concepts.
Licensing
- The software can be installed on multiple computers. The number of existing licenses determines the number of computers on which the software can be used simultaneously (floating license).
- An upgrade to the subsequent version is offered for users of previous versions.
- A rental license is available for temporary use
- A trial license is available for testing purposes.
- It is possible to conclude Software Update Service (SUS) contracts.
You can find more information on the Software Update Service, license types, Online Software Delivery and handling your SW licenses with the Automation License Manager under this link.
Benefits
- Automatic creation of visualizations – drastic reduction of the engineering time
- Reduction of the commissioning times by the early detection and avoidance of faults
- Adaptation at the touch of a button to the visualizations on the basis of changes/adaptations in the control program
Function
- Support of controllers:
- S7-1200, S7-1500, ET 200SP
- Support of HMI:
- Unified Comfort Panels and Unified Basic Panels
- Basic Panels, Comfort Panels and Mobile Panels of the 2nd Generation
- Support of PC-based:
- WinCC Unified PC
- WinCC Runtime Advanced, WinCC Runtime Professional
- S7-1500 Software Controller
- SiVArc is configured using rules (not programmed!)
6AV2107-3PX02-3AA5
Siemens SIMATIC Visualization Architect V19 (SiVArc), upgrade V18 -> V19; engineering software in TIA Portal; software and documentation on CD, license key on USB flash drive; class A; 6 languages: de,en,fr,es,it,zh. - - content: set (1x DVD + 1x USB)
Visit 6AV2107-3PX02-3AA5
