6BK1801-1AA10-0AB0 Siemens SIMATIC IPC1047E Original Brand New

Highest industrial compatibility for 24/7 continuous use in an industrial environment

• Product design for up to 50 °C ambient temperature
• All-metal housing with high EMC for use in industrial environments
• Dust protection thanks to overpressure ventilation concept with fan on the front and dust filter
• Securing of the replaceable components at the front (e.g. USB software dongle, drives) against unauthorized access by means of a lockable door
• Locked fan cover: Filter mat and front fan can only be replaced when front door is open
• Enclosure cover can only be opened when the front door is open

Security by default

• Securing of the replaceable components at the front (e.g. USB software dongle, drives) against unauthorized access by means of a lockable door
• Locked fan cover: Filter mat and front fan can only be replaced when front door is open
• Enclosure cover can only be opened when the front door is open
• Security settings active from delivery state, e.g. passwords, ports, interfaces

Maximum performance in plant environment

• Two Intel® Xeon® SP Gold/ Silver 2nd generation processors with up to 40 CPU cores
• Supports hyperthreading and virtualization technology
• Up to two NVIDIA® Quadro® RTX4000 High End graphics cards for maximum graphic, computing and AI capacities
• Maximum performance with up to 2 TB DDR4 EEC – work memory
• High data transfer rates with PCI Express 3.0, USB 3.0, SATA3 (6 Gbps), Gigabit LAN, M.2 and U.3
• High expandability with 6x PCIe cards (2x PCIe x8 and 4x PCIe x16 lanes)
• Large data memory 8x SSDs or 4x HDDs (up to 32 TB memory space)
• Fast data access with solid state drive (SSD) and M.2/U.3 NVMe (5x faster than SSD)
• High performance for customer requirements with 860 W power supply unit

Minimization of downtimes thanks to high system availability

• Secured 24-hour operation (high MTBF, variable-speed fan) at ambient temperature up to 50 °C
• High data security due to powerful RAID controller hardware
• Status display (front LEDs) for voltage, HDD access and alarm display for fan
• Remote control and remote maintenance via IPMI 2.0 (Intelligent Platform Management Interface)
• Redundant AC power supply unit with hot swap functionality (replacement of power supply module during operation), optional
• Redundant Gbit LAN connections
• Service-friendly device design (modifications, service), e.g. filter replacement without the need for tools

Cost reductions through high investment security

• Platform with embedded Intel components for long-term stability
• Available for 4 to 6 years, assured spare parts availability for 5 years
• Certifications for worldwide marketing (CE/ cULus/ KC)

Reduced costs due to time savings for commissioning, operation and servicing

• High flexibility and expandability thanks to integrated interfaces and up to 6 PCI slots
• Preinstalled and activated operating system
• Fast restoration of delivery state using restore USB flash drive
• Universal implementation as an industrial workstation or server
• Hardware RAID 0, 1, 5, 10
• Software RAID 0, 1, 5, 10
• 2 x LAN 1000 Mbps connections
• Remote maintenance with IPMI 2.0 technology
