6DR5113-0NM01-0AA0 SIEMENS SIPART PS2 Positioner
6DR5113-0NM01-0AA0 SIEMENS SIPART PS2 Positioner

6DR5113-0NM01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

Model / SKU6DR5113-0NM01-0AA0

SIEMENS 6DR5113-0NM01-0AA0 SIPART PS2 electropneumatic positioner with 4–20 mA HART, non-contact sensor, single-acting, aluminum housing, for pneumatic actuators.

$4,038.95
Available on backorder
  • ConditionOriginal Brand New
  • Warranty12 months

Backorder available · Factory lead time 2–3 weeks.

Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

6DR5113-0NM01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

SIPART PS2 Smart, electropneumatic positioner, 4...20mA, HART, Ex/nEx, single-acting, aluminum enclosure, for pneumatic linear and part-turn actuators. Non-contacting (wear-free) position detection (NCS). Not in combination with pressure sensor option P01/P02. Standard Without explosion protection. Connection thread el.: M20x1.5 / pneu.: 1/4" NPT Without limit monitor. Analog Output Module (AOM), analog position feedback 4 ... 20 mA. Device plug M12 optionally orderable with -Z D53. Isolating power supply SITRANS I100 separately orderable (7NG4124-1AA00). . Brief instructions English / German / Chinese. Standard / Fail-Safe - Depressurizing the actuator in case of failure of electrical auxiliary power (single acting only). Without Manometer block / Booster.

The 6DR5113-0NM01-0AA0 SIEMENS SIPART PS2 is a smart, electropneumatic positioner engineered for precise valve control in industrial automation applications. With a 4–20 mA input signal and HART communication protocol, this single-acting device is housed in a robust aluminum enclosure, offering non-contacting (wear-free) position detection through NCS technology.

Optimized for use with pneumatic linear and part-turn actuators, this unit provides analog position feedback (4–20 mA) via an Analog Output Module (AOM). Built to deliver consistent performance even in harsh environments, it supports fail-safe functionality that depressurizes the actuator in the event of electrical auxiliary power loss. It is compatible with additional modules, including inductive or mechanical limit switches, digital I/O, and analog outputs.

Overview

SIPART PS2 positioners control valve movement based on setpoint values and offer extensive online and offline diagnostic functions. These diagnostics can be expanded with pressure sensors to provide enhanced visibility into valve health and operation, helping reduce unplanned downtime and improve overall system reliability.

Design

The digital positioner consists of:

  • Base plate with or without an inspection window
  • Electronics with screw-type terminals for 4–20 mA or 4–20 mA with HART
  • Non-contacting position detection via NCS
  • Pneumatic block with standard 1/4" NPT pneumatic connection and M20x1.5 electrical thread

Optional features include:

  • Analog Output Module (AOM) for analog feedback (4–20 mA)
  • Digital I/O Module with configurable alarms and signal outputs
  • Inductive or mechanical limit switches (ILS/MLS) for position monitoring

The device allows separate mounting of the positioner and position detection unit, which is beneficial in environments with harsh ambient conditions such as high vibration, radiation, or magnetism. The components can be connected electrically and pneumatically for flexible installation.

Product Code: 6DR5113-0NM01-0AA0

More Siemens products at Turll.com

Specifications

SKU / Model6DR5113-0NM01-0AA0
Weight1.6 kg
