6DR7111-0AN11-1BA0 SIEMENS Exclusive SIPART PS100 Electropneumatic Positioner Original Brand New

Model / SKU6DR7111-0AN11-1BA0

SIEMENS SIPART PS100 electropneumatic positioner for valve control. Compact, wear-free, easy setup, with analog output and HART communication.

$3,906.11
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

6DR7111-0AN11-1BA0 SIEMENS Exclusive SIPART PS100 Electropneumatic Positioner Original Brand New

SIPART PS100 electropneumatic positioner with a 4 to 20 mA input automates control valves. The positioner enclosure has an aluminum lid without a viewing window. It is suitable for single and double-acting linear and part-turn actuators. Positioner knowledge is not required. Commissioning is done at the push of a button. Single-acting Without explosion protection 2-wire, 4 ... 20 mA, HART without device option 1 with analog output (AO) 4 ... 20 mA Thread of the lower cable entry: M20 x 1.5 / with cable gland plastic Thread of the upper cable entry: M20x1.5 / with cable gland plastic with pneumatic thread 1/4-18 NPT without pressure gauge block Without other designs

The SIEMENS SIPART PS100 positioner, with part number 6DR7111-0AN11-1BA0, offers exceptional control performance for pneumatic actuators in industrial environments. Designed for automation of control valves and dampers, this model features a compact and rugged build with a no-viewing-window aluminum lid, suitable for both single and double-acting linear or part-turn actuators.

With a straightforward commissioning process that requires only a single button press, the positioner allows fast setup without the need for specialized knowledge. Operating with a 2-wire system and a 4 to 20 mA analog signal, this model also supports HART communication. It includes an analog output (AO) for providing feedback on valve position.

Installation is made simple with dual M20 x 1.5 threaded cable entries, each equipped with plastic cable glands. The device uses a 1/4-18 NPT pneumatic thread and does not include pressure gauge blocks or additional device options, making it ideal for standard configurations.

Overview

The SIPART PS100 electropneumatic positioner controls the valve or damper position of pneumatic actuators according to an analog setpoint signal. It ensures precision regulation and is especially useful in automated process applications requiring efficiency and reliability.

Design

The positioner consists of:

  • A durable enclosure made of base plate and aluminum lid
  • Electronics with contact-free position detection for long-term reliability
  • An integrated pneumatic block located on the right side of the housing
  • Electrical connections on the left side for ease of access

The shaft connection is located beneath the housing and is connected to the actuator via an appropriate mounting kit, ensuring accurate mechanical linkage.

Additional features include:

  • 4–20 mA analog output for valve position feedback
  • Optional digital input/output for alarm signaling and position monitoring
  • Support for HART communication for diagnostics and parameter setting

Product Code: 6DR7111-0AN11-1BA0

More Siemens products at Turll.com

Specifications

SKU / Model6DR7111-0AN11-1BA0
Weight1.055 kg
