6ES7212-1HG50-0XB0 Siemens SIMATIC S7-1200 G2 Compact CPU 1212C Original Brand New
$299.64
6ES7212-1HG50-0XB0
Siemens SIMATIC S7-1200 G2: compact CPU 1212C DC/DC/RLY; power supply: DC 20.4-28.8 V DC; onboard I/O: 8x DI 24 V DC; 6 DO relay 2 A; memory: program 150 KB data: 500 KB, retentivity: 20 KB
Global Express Shipping
DHL / FedEx / UPS
100% Original & Brand New
Factory Sealed Box with 1-Year Warranty
Secure Payment
SSL ENCRYPTED
[ez-toc]
6ES7212-1HG50-0XB0
Siemens SIMATIC S7-1200 G2: compact CPU 1212C DC/DC/RLY; power supply: DC 20.4-28.8 V DC; onboard I/O: 8x DI 24 V DC; 6 DO relay 2 A; memory: program 150 KB data: 500 KB, retentivity: 20 KB
Overview
- Controller for getting started with S7-1200 G2
- Expandable by:
- 1 signal board (SB)
- 8 signal modules (SM)
Design
The compact CPU 1212C has:
- 3 device versions with different power supply and control voltages.
- Integrated power supply either as wide-range AC or DC power supply (85 … 264 V AC or 24 V DC)
- Integrated 24 V encoder/load current supply:
For direct connection of sensors and encoders. With 300 mA output current also for use as load current supply. - 8 integrated digital inputs 24 V DC (sinking input/sourcing input (IEC type 1 sinking input)).
- 6 integrated digital outputs, either 24 V DC or relay.
- 10 Motion technology objects
- 8 pulse outputs (PTO) with a frequency of up to 100 kHz.
- Pulse-width modulated outputs (PWM) with a frequency of up to 100 kHz.
- Integrated PROFINET interface (TCP/IP native, ISO-on-TCP).
- 8 high-speed counters (3 with max. 100 kHz; 1 with max. 30 kHz), with configurable enable and reset inputs, can be used simultaneously as up and down counters with 2 separate inputs or for connecting incremental encoders.
- Expansion by analog or digital signals directly on the CPU via signal board (with retention of CPU mounting dimensions).
- Expansion by a wide range of analog and digital input and output signals via signal modules.
- Optional memory expansion (SIMATIC Memory Card).
- Integrated PID controller with auto-tuning functionality.
- Program alarm.
- Near Field Communication (NFC) for mobile device access to the CPU.
- Integral real-time clock.
- Interrupt inputs:
For extremely fast response to rising or falling edges of process signals. - Removable push-in clamps on all modules.
Function
- Comprehensive instruction set:
A wide range of operations facilitates programming:- Basic operations such as binary logic operations, result allocation, save, count, create times, load, transfer, compare, shift, rotate, create complement, call subprogram (with local variables)
- Integral communication commands (e.g. USS protocol, Modbus RTU, S7 communication “T-Send/T-Receive” or Freeport)
- User-friendly functions such as pulse-width modulation, pulse sequence function, arithmetic functions, floating-point arithmetic, PID control, jump functions, loop functions and code conversions, Motion technology objects
- Mathematical functions, e.g. SIN, COS, TAN, LN, EXP.
- Counting:
User-friendly counting functions in conjunction with the integrated counters and special commands for high-speed counters open up new application areas for the user. - Interrupt processing:
- Edge-triggered interrupts (activated by rising or falling edges of process signals on interrupt inputs) support a rapid response to process events
- Program interrupts
- Time-triggered interrupts
- Counter interrupts can be triggered when a setpoint is reached or when the counting direction changes
- Communication interrupts allow the rapid and easy exchange of information with peripheral devices such as printers or bar code readers
- Password protection
- Test and diagnostics functions:
Easy-to-use functions support testing and diagnostics, e.g. online/offline diagnostics. - “Forcing” of inputs and outputs during testing and diagnostics:
Inputs and outputs can be set independently of the cycle and thus permanently, for example, to test the user program. - Motion Control in accordance with PLCopen for simple control of movement
- Library functionality
Programming
The STEP 7 Basic programming package permits complete programming of all S7-1200 Controllers and the associated I/O.
Visit 6ES7212-1HG50-0XB0
For more our products visit turll.com
| Weight | 0.333 kg |
|---|---|
| Dimensions | 80 × 136 × 110 mm |
