6ES7545-5DA00-0AB0 SIEMENS Exclusive SIMATIC DP CM PROFIBUS DP Module Original Brand New

6ES7545-5DA00-0AB0 SIEMENS Exclusive SIMATIC DP CM PROFIBUS DP Module Original Brand New

The 6ES7545-5DA00-0AB0 SIEMENS SIMATIC DP CM PROFIBUS DP module is a high-quality communication module designed for ET 200SP CPU integration, offering seamless and efficient PROFIBUS DP connectivity. This module enables robust data exchange in industrial automation environments, serving as both a DP master for up to 125 DP slaves and as a DP slave for higher-level networks. With a maximum transmission speed of 12 Mbps, it ensures rapid and stable communication between connected devices.

Ideal for expanding ET 200SP CPUs such as 1510SP-1 PN and 1512SP-1 PN, this module adds a dedicated PROFIBUS port for integration into complex network infrastructures. It supports a wide range of communication services, including PG/OP communication, time synchronization, and cross-network programming through S7 routing. Configuration and diagnostics are simplified via the integrated interface, reducing commissioning time and enhancing productivity.

Overview

The module provides an electrical PROFIBUS interface via a 9-pin D-sub socket. It allows direct communication with various automation components, including those from the SIMATIC S7-300, S7-400, and S7-1500 series. Supported data rates range from 9.6 Kbps to 12 Mbps, offering flexibility for different application requirements.

Design

This unit features a compact and modular ET 200SP form factor. Power is supplied through the backplane bus, eliminating the need for external wiring. Key design elements include:

• Integrated “DIAG” LED for quick status checks
• Snap-on DIN rail mounting for fast installation
• User-friendly wiring with easily accessible D-sub socket
• Positioned directly adjacent to the ET 200SP CPU for optimal performance

Download

Data Sheet (PDF)

Product Code: 6ES7545-5DA00-0AB0

More Siemens products at Turll.com
