6ES7661-1JA01-1CA3 SIEMENS Exclusive SIMATIC IPC847E PCS 7 Single Station Original Brand New
For price details, please contact our customer service
The SIEMENS 6ES7661-1JA01-1CA3 is a robust SIMATIC IPC847E industrial rack PC engineered for PCS 7 ES/OS single station and OS client applications. Powered by the Intel Xeon E-2176G processor (6 cores, 12 threads, 3.7 GHz base clock, up to 4.7 GHz turbo), this 4U rackmount system ensures powerful computing performance for process control environments. It comes preinstalled with PCS 7 V9.1 SP2 and Windows 10 Enterprise 2019 LTSC, providing reliable and seamless integration within SIMATIC PCS 7 systems. With 2 TB enterprise-grade HDD storage and 16 GB DDR4 RAM, this system supports heavy industrial workloads with high availability.
Overview
6ES7661-1JA01-1CA3 Designed with durability and flexibility in mind, the IPC847E features a ruggedized all-metal 19-inch 4U chassis with advanced cooling, temperature and fan monitoring, and watchdog functionality. Its extended expansion capability with 11 total slots (including PCI, PCIe x16, PCIe x4) allows broad scalability for industrial applications. The system includes comprehensive connectivity such as multiple USB 3.1 ports, DisplayPort, DVI-D, and triple Gbit LAN interfaces, ensuring versatility for complex installations. Engineered for continuous 24/7 operation in challenging industrial environments, it withstands up to 5 g shock and 0.5 g vibration, making it a trusted choice for mission-critical PCS 7 systems.
- Intel Xeon E-2176G (6 cores/12 threads, 3.7 GHz base, 4.7 GHz turbo, 12 MB cache)
- Preinstalled PCS 7 V9.1 SP2 with Windows 10 Enterprise 2019 LTSC (64-bit)
- 2 TB Enterprise-grade HDD (3.5″ SATA)
- 16 GB DDR4 SDRAM (2x 8 GB), Dual Channel
- 11 expansion slots: 3x PCI, 1x PCIe x16 (8 lanes), 5x PCIe x16 (4 lanes), 2x PCIe x4 (4 lanes)
- Temperature and fan monitoring, watchdog, card retainer
- Interfaces: 3x Gbit LAN (RJ45), 1x DVI-D, 2x DisplayPort, 1x COM, Audio
- USB Ports: 4x USB 3.1 Gen2 (rear), 2x USB 3.1 Gen2 Type C (rear), 2x USB 3.1 (front), 1x USB 3.1 internal
- Rugged industrial 100/240 V AC power supply with China power cord
Design
- Industrial-grade 19″ 4U rackmount chassis with robust mechanical and electromechanical design
- Reliable 24/7 continuous operation at ambient temperatures between 5°C and 50°C
- Shock resistant up to 5 g and vibration resistant up to 0.5 g during operation
- Integrated with monitoring features for industrial reliability
- Optimized for compact installation within standard control cabinets
- Supports flexible system expansion for industrial control applications
Product Link: 6ES7661-1JA01-1CA3
