6GK5004-2BF00-1AB2 SIEMENS SCALANCE XB004-2LD Unmanaged Industrial Ethernet Switch Original Brand New

SIEMENS SCALANCE XB004-2LD – 6GK5004-2BF00-1AB2

SCALANCE XB004-2LD unmanaged Industrial Ethernet Switch for 10/100 Mbit/s; for setting up small star and line topologies; LED diagnostics, IP20, 24 V AC/DC power supply, with 4x 10/100 Mbit/s twisted pair ports with RJ45 sockets; 2 x 100 Mbit/s single-mode glass fiber-optic cable port with SC socket. Manual available as a download.

Overview

The unmanaged Industrial Ethernet switches of the SCALANCE XB-000 line are ideal for setting up small Industrial Ethernet networks in line and star topologies. Their enclosures are suitable for space-saving installation in control cabinets or boxes on standard DIN rails.

Product Variants

• SCALANCE XB005 / XB008: 5 or 8 x 10/100 Mbps RJ45 ports
• SCALANCE XB005G / XB008G: 5 or 8 x 10/100/1000 Mbps RJ45 ports
• SCALANCE XB004-1: 4 x RJ45, 1 x SC (multimode, up to 5 km)
• SCALANCE XB004-2: 4 x RJ45, 2 x SC (multimode, up to 5 km)
• SCALANCE XB004-1LD / XB004-2LD: single-mode SC ports up to 26 km
• SCALANCE XB004-1G: 4 x RJ45 (Gigabit), 1 x SC multimode up to 750 m
• SCALANCE XB004-1LDG: 1 x SC single-mode up to 10 km

Design Features

SCALANCE XB-000 switches are optimized for DIN-rail installation and support wall mounting. Features include:

• 3-pin terminal block (24 V DC) with functional grounding
• LED indicators for power, link, and data activity per port
• Front-facing data ports; power input located at the bottom

Port Types Available

• 10/100 BaseTX or 10/100/1000 BaseTX electrical RJ45 ports (autosensing/autocrossing, up to 100 m cables)
• 100 BaseFX SC multimode (up to 5 km)
• 100 BaseFX SC single-mode (up to 26 km)
• 1000 BaseSX SC multimode (up to 750 m)
• 1000 BaseLX SC single-mode (up to 10 km)

Product code: 6GK5004-2BF00-1AB2
