6GK5334-2TS00-2ER3 SIEMENS SCALANCE XR326-8EEC Exclusive Managed IE Switch Brand New Original

6GK5334-2TS00-2ER3 SIEMENS SCALANCE XR326-8EEC Exclusive Managed IE Switch Brand New Original

SCALANCE XR326-8EEC managed Layer 2 IE switch; 19″ rack-mountable; 24x 100/1000 Mbps RJ45 ports; 2x 1G/2.5G/5G/10G RJ45 ports; 8x 1G/10G SFP+ ports; conformal coating; LED diagnostics; error signaling contact; select/set button; PROFINET IO device; network management; integrated redundancy manager; office features (RSTP, VLAN, IGMP); CLP included; 24 V DC power supply

Overview

The Siemens SCALANCE XR326-8EEC (6GK5334-2TS00-2ER3) is an exclusive 19-inch rack-mounted managed Layer 2 Industrial Ethernet switch from the XR-300EEC series, designed for high-performance industrial networks with data rates up to 10 Gbps. It features 24 Fast/Gigabit RJ45 ports, 2 multi-rate RJ45 uplinks (up to 10 Gbps), and 8 SFP+ ports for high-speed optical connectivity.

This variant includes conformal coating for enhanced environmental protection and operates on 24 V DC. It supports PROFINET IO diagnostics, integrated redundancy protocols, and advanced VLAN segmentation. With LED diagnostics, CLP configuration memory, and rugged IP20 housing, the XR326-8EEC is an exclusive solution for scalable, secure, and resilient industrial automation infrastructure.

Key Features

• 24 x 100/1000 Mbps RJ45 electrical ports
• 2 x 1G/2.5G/5G/10G RJ45 multi-rate uplink ports
• 8 x 1G/10G SFP+ ports for optical uplinks
• IEC 62443-4-2 certified; PROFINET IO and EtherNet/IP compatible
• Conformal coating for harsh environments
• Integrated redundancy manager (MRP, HRP, RSTP, PRP, HSR)
• LED diagnostics and select/set pushbutton
• Console port and signaling contact
• VLAN, IGMP snooping, ACL, IEEE 802.1X
• 24 V DC power supply via 2x 2-pin terminal block
• IP20 metal enclosure; fanless design
• Operating temperature: –40 °C to +60 °C
• 19″ rack-mountable; low installation depth

Product Code: 6GK5334-2TS00-2ER3
