6GK5534-5TR00-2AR3 SIEMENS Exclusive SCALANCE XR502-32 Layer 3 Switch Original Brand New

6GK5534-5TR00-2AR3 SIEMENS Exclusive SCALANCE XR502-32 Layer 3 Switch Original Brand New

SCALANCE XR502-32 Layer 3 managed Industrial Ethernet switch in 19" rack format with 2x 1G/2.5G/5G/10G RJ45 ports, 24x 100M/1G SFP ports, and 8x 1G/10G SFP+ ports. Equipped with advanced diagnostics, error signaling, and integrated redundancy manager. Includes PROFINET IO, network management functions, and CLP removable memory. Power supply: 24 V DC.

Overview

The Siemens SCALANCE XR502-32 is a high-performance, modular Layer 3 Industrial Ethernet switch designed for backbone network structures with high bandwidth demands. Offering a robust configuration of optical SFP and SFP+ ports and multi-gigabit RJ45 connections, this unit supports full integration into both automation and corporate networks.

• 2x 1G/2.5G/5G/10G multigigabit RJ45 ports
• 24x 100M/1G SFP ports for flexible optical connections
• 8x SFP+ slots supporting 1G/10G high-speed uplinks
• Support for VLAN, IGMP Snooping, RSTP/MSTP/STP, QoS, Link Aggregation
• Advanced routing features with optional KEY-PLUG (OSPF, RIP, VRRP)
• PROFINET IO device support with diagnostics via SINEC NMS, SNMP, CLI, Web
• CLP removable storage for easy device replacement
• Redundant topologies with integrated media redundancy manager

Design

• 19" metal rackmount housing with IP20 rating
• 24 V DC power input via terminal block
• LED indicators for link status, power, traffic, and diagnostics
• Fault contact and SELECT/SET button for easy alarm configuration
• Console port for local diagnostics and setup
• Slot for CLP or optional KEY-PLUG (routing enablement)
• Support for multimode and single-mode SFP/SFP+ transceivers

Product Link: 6GK5534-5TR00-2AR3
