The 6SL3202-0AE23-3SA0 SIEMENS sine-wave filter is engineered to enhance motor protection and improve the overall performance of SINAMICS drive systems. Built for compatibility with PM230, PM240, and PM250 Power Modules within the FSC base frame, this filter delivers efficient voltage smoothing to ensure cleaner and more stable motor operation. Its ability to significantly reduce the rate of voltage rise and peak voltages across motor windings helps extend motor life, especially in applications where longer motor cables are required. By minimizing harmful electrical stress, the filter creates a more controlled operating environment and supports steady performance even in demanding installations.

This sine-wave filter provides substantial benefits for applications that require reduced electromagnetic interference and improved cable compatibility. The lowered dv/dt values make it easier to integrate standard motors without the need for insulated bearings or reinforced insulation. Users can also expect reduced acoustic noise, as the smoother voltage waveform decreases converter-related disturbances. The resulting operation more closely resembles that of motors fed directly from the mains, offering a quieter and more refined system behavior.

When implemented within automation environments, the 6SL3202-0AE23-3SA0 helps ensure compliance with EMC guidelines, often reducing the necessity for shielded cables in shorter configurations. The filter supports pulse frequencies between 4 kHz and 8 kHz, with maximum output frequency capped at 150 Hz. It is important to note that commissioning must always be performed with the motor connected, as the unit is not designed for no-load operation. Additionally, automatic pulse frequency reduction functions must be disabled to ensure proper performance.

With its dependable design and purpose-built characteristics, this sine-wave filter enhances system durability, improves motor compatibility, and creates a stable, efficient foundation for a wide range of electrical drive applications.

Overview

Sine-wave filters reduce dv/dt stress, lower motor winding peak voltages, and allow the use of longer motor cables. They also minimize bearing currents, enabling operation of standard motors without specialized insulation. Their low voltage rise behavior improves EMC performance and reduces converter-related noise. The filter operates within defined pulse frequency limits and must only be commissioned with the motor connected.

Product Code: 6SL3202-0AE23-3SA0
