7ML5320-0AA06-0AH0 SIEMENS Exclusive SITRANS LR120 Radar Level Transmitter Original Brand New

7ML5320-0AA06-0AH0 SIEMENS Exclusive SITRANS LR120 Radar Level Transmitter Original Brand New

The SIEMENS 7ML5320-0AA06-0AH0 SITRANS LR120 is an advanced, compact radar level transmitter engineered for continuous, non-contact measurement of liquids, slurries, and solids with a range capability of up to 30 meters (98.4 ft). Designed for high reliability and minimal maintenance, this transmitter features an integrated cable connection and supports HART 4...20 mA communication, ensuring seamless integration into industrial control systems. The device is suitable for ordinary locations and adheres to cFMus, cCSAus, CE, and RCM certifications, guaranteeing compliance with global safety and performance standards.

The LR120 utilizes W band FMCW radar technology to achieve a narrow beam angle, delivering exceptional accuracy even in environments with obstructions. With a chemically resistant PVDF enclosure, it is built for durability and long-term stability, even in harsh conditions. The transmitter’s 2 mm measurement accuracy and zero near range capability make it an ideal choice for precise inventory management in both open-air applications and closed tank environments.

Overview

Compact and robust, the SITRANS LR120 is optimized for applications requiring consistent, high-quality level monitoring. Whether in wet wells, silos, or process vessels, its design ensures reliable performance in both liquid and solid measurement scenarios.

Benefits

• Bluetooth connectivity for quick configuration using SITRANS mobile IQ.
• PVD-resistant housing for chemical protection.
• HART 7.0 or Modbus RTU compatibility for intelligent process integration.
• High-precision radar with sub-2 mm accuracy.
• Approvals for open-air and hazardous area use.
• Submergence shield accessory to prevent buildup during flooding.

Application

Ideal for aggregates, plastic pellets, and wet well monitoring, the LR120 delivers dependable readings under challenging process conditions. It combines modern wireless setup options with traditional wired connectivity, offering unmatched installation flexibility.

Product Code: 7ML5320-0AA06-0AH0
