7ML5340-0AC07-4AK3 SIEMENS Exclusive SITRANS LR150 Radar Level Transmitter Original Brand New

7ML5340-0AC07-4AK3 SIEMENS Exclusive SITRANS LR150 Radar Level Transmitter Original Brand New

The SIEMENS 7ML5340-0AC07-4AK3 SITRANS LR150 radar level transmitter is a high-quality, non-contact solution designed for accurate and reliable level measurement in industrial applications. Built with a measuring range of up to 15 meters (49.2 feet), this transmitter is suitable for monitoring liquids, slurries, and solids in various process environments. Its compact design makes it ideal for installations where space is limited, while its robust construction ensures long-term durability and dependable performance even under demanding operating conditions.

The transmitter features a clear display with a polycarbonate window, allowing easy visibility of level data in real time. Installation is simplified by the G 1-1/2” BSPP process connection, while electrical connection is supported through a 1/2" NPT cable entry. The LR150 is equipped with HART 7.0 communication for seamless integration into automation systems, enabling flexible configuration and efficient data transfer. The advanced W band FMCW radar technology ensures a narrow beam angle, high measurement accuracy, and reliable results, even in challenging short-range applications. This makes it an excellent solution for inventory management, storage monitoring, and process control.

Overview

The SITRANS LR150 is a compact radar transmitter designed for continuous measurement of liquids and solids. With a measuring capability up to 15 meters, it is engineered to deliver reliable performance across a wide range of applications, including chemical storage, water treatment, and material handling.

Benefits

• Optional Bluetooth connectivity for wireless setup and operation with the SITRANS mobile IQ application.
• Clear local HMI with pushbutton programming and diagnostic capability.
• Compact design with chemically resistant PVDF sensor for long service life.
• Accurate level monitoring with 2 mm precision and zero near range distance.
• Approved for both tank applications and open-air installations.
• Hazardous area variants available for safe operation in explosive gas or dust environments (pending).

Application

The SITRANS LR150 delivers continuous, loop-powered level measurement using 4 to 20 mA output with HART communication. It can measure through plastic vessel tops for simplified installation without direct process contact. The transmitter is ideal for industries requiring precise inventory management and reliable level detection. Programming is flexible, whether through the mobile IQ app via Bluetooth or the optional HMI for local setup and control.

Product Code: 7ML5340-0AC07-4AK3
