Siemens SIRIUS 3RT7016-1AV02 Contactor AC-3, 9A, 4kW, 400V, Screw Terminal, Size S00 Original Brand New

Product Overview: Siemens 3RT7016-1AV02 SIRIUS Contactor

The Siemens 3RT7016-1AV02 is a high-performance SIRIUS series contactor designed for reliable motor switching and general industrial applications. Part of the compact and versatile S00 size range, this contactor is engineered to handle demanding AC-3 loads up to 9A and 4kW at 400V. Its robust design and high-quality components ensure long service life and exceptional operational stability.

Key Features & Benefit

• Compact Design (Size S00): The small footprint of the S00 size allows for space-saving installation in control panels and cabinets, making it an ideal choice for compact machinery.
• High Performance: Rated for AC-3 duty, it is perfectly suited for switching squirrel-cage motors with high starting currents, ensuring reliable and safe operation.
• Integrated Auxiliary Contact: Includes one (1) Normally Closed (NC) auxiliary contact, providing essential feedback or interlocking capabilities for your control circuit.
• Efficient Coil: The AC 400V 50/60Hz coil is energy-efficient and provides reliable switching performance in a wide range of industrial power systems.
• Secure Screw Terminals: Features durable and easy-to-use screw terminals for a strong, vibration-resistant electrical connection. This widely-used terminal type simplifies wiring and maintenance.
• Part of the SIRIUS Modular System: Seamlessly integrates with other Siemens SIRIUS components, such as overload relays and circuit breakers, for a complete and scalable motor starter solution.

Technical Specification

• Product Number: 3RT7016-1AV02
• Contactor Type: Power Contactor
• Series: SIRIUS
• Size: S00
• Rated Operational Current (Ie): 9 A (at 400V, AC-3)
• Rated Power (kW): 4 kW (at 400V, AC-3)
• Rated Insulation Voltage (Ui): 690 V
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Auxiliary Contacts: 1 NC (Normally Closed)
• Coil Voltage: 400 V AC, 50/60 Hz
• Terminals: Screw Terminals
• Mounting: DIN rail or screw fixing

Application

The Siemens 3RT7016-1AV02 contactor is the go-to component for a wide range of applications, including:

• Switching of electric motors (e.g., pumps, fans, conveyors)
• Controlling resistive loads (e.g., heating elements, lighting systems)
• Integration into motor starters, control panels, and automation systems
• Used in a variety of industries such as manufacturing, HVAC, and material handling

For a complete solution, consider pairing this contactor with a matching Siemens SIRIUS overload relay.
