Siemens 3SU1401-1BB20-3AA0 LED Module 24V AC/DC, Red, Spring-Loaded Terminal, Front Plate Mounting Original Brand New
$3.51
LED module with integrated red LED, 24 V AC/DC, spring-loaded terminal, and front plate mounting.
Availability: In stock
Overview
The Siemens 3SU1401-1BB20-3AA0 LED Module is engineered for reliable signaling performance in industrial control systems. Designed with an integrated LED, this module delivers bright, clear red indication and operates on 24 V AC/DC, making it ideal for a wide range of automation applications. The spring-loaded terminal ensures fast, secure wiring, while front plate mounting allows smooth integration into control panels and operator devices.
Minimum order quantity: 5 units (or multiples of 5).
Key Benefit
-
High Visibility: Bright red LED provides clear optical signaling for operational safety.
-
Easy Installation: Spring-loaded terminals enable quick, tool-free wiring.
-
Long Service Life: Integrated LED technology ensures stable, energy-efficient performance.
-
Flexible Integration: Ideal for control panels, machine interfaces, and industrial automation systems.
-
Reliable Siemens Quality: Manufactured to meet strict industrial standards for durability and performance.
Function
-
Provides visual signaling for machine status, alerts, and operation modes
-
Integrates seamlessly into pushbutton and indicator assemblies
-
Ensures consistent illumination under 24 V AC/DC supply
-
Supports front plate mounting for a clean and secure control panel layout
Technical Features
-
Part Number: 3SU1401-1BB20-3AA0
-
LED Color: Red
-
Operating Voltage: 24 V AC/DC
-
Mounting Type: Front plate mounting
-
Terminal Type: Spring-loaded terminal
-
Category: LED indicator module
-
Minimum Order: 5 units or multiples of 5
Download
Visit 3SU1401-1BB20-3AA0 for more detail info
For more our products visit turll
| Weight | 0.008 kg |
|---|---|
| Dimensions | 37.00 × 104.00 × 17.00 mm |
| Brand | SIEMENS |
| product brand name | SIRIUS ACT |
| product designation | LED module |
| product type designation | 3SU1 |
| product component | – |
| ● diode | Yes |
| ● lamp transformer | No |
| ● light source | Yes |
| ● series resistor | No |
| insulation voltage rated value | 320 V |
| degree of pollution | 3 |
| type of voltage of the operating voltage | AC/DC |
| ● for actuation | AC/DC |
| surge voltage resistance rated value | 4 kV |
| consumed current maximum | 25 mA |
| protection class IP | – |
| ● of the enclosure | IP40 |
| ● of the terminal | IP20 |
| shock resistance | – |
| ● acc. to IEC 60068-2-27 | Sinusoidal half-wave 50g / 11 ms |
| vibration resistance | – |
| ● acc. to IEC 60068-2-6 | 10 … 500 Hz: 5g |
| ● for railway applications acc. to DIN EN 61373 | Category 1, Class B |
| operating period typical | 100 000 h |
| reference code acc. to IEC 81346-2 | P |
| operating voltage 1 | – |
| ● at AC | – |
| — at 50 Hz rated value | 24 V |
| — at 60 Hz rated value | 24 V |
| ● at DC rated value | 24 V |
| relative positive tolerance of the operating voltage | 25 % |
| relative negative tolerance of the operating voltage | 30 % |
| inrush current maximum | 2 A |
| type of electrical connection | spring-loaded terminals |
| type of connectable conductor cross-sections | – |
| ● solid without core end processing | 2x (0.25 … 1.5 mm²) |
| ● finely stranded with core end processing | 2x (0.25 … 0.75 mm²) |
| ● finely stranded without core end processing | 2x (0.25 … 1.5 mm²) |
| ● at AWG cables | 2x (24 … 16) |
| type of light source | LED |
| color of the light source | red |
| light intensity | 450 … 1 120 mcd |
| certificate of suitability | – |
| ● ATEX | No |
| ● IECEx | No |
| ambient temperature | – |
| ● during operation | -25 … +70 °C |
| ● during storage | -40 … +80 °C |
| environmental category during operation acc. to IEC 60721 | 3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 … 95 %, no condensation in operation permitted) |
| fastening method | – |
| ● of modules and accessories | Front plate mounting |
| last modified: | 10/6/2021 |
