Siemens 3TB4022-0XK1 Contactor, 120V AC, 9A, 4kW Size 0, 1NO + 1NC Original Brand New

Overview

The Siemens 3TB4022-0XK1 is a robust and reliable AC contactor designed for a wide range of industrial control and power applications. Engineered for optimal performance and durability, this device is a key component in electrical circuits for switching motors, lighting, and other loads. Its compact Size 0 frame makes it suitable for integration into various control panels and machinery.

This specific model operates with a 120V AC, 60 Hz control voltage, making it a standard choice for North American industrial environments. It is rated for a nominal current of 9A for AC-3 applications at 400V, with a corresponding power rating of 4 kW. The inclusion of one normally open (1 NO) and one normally closed (1 NC) auxiliary contact provides essential flexibility for interlocking and control circuit feedback. The straightforward screw connection terminals ensure secure and reliable wiring.

Key Benefit

• Reliable Performance: Siemens’ reputation for quality ensures consistent and dependable operation in demanding industrial settings.
• Versatile Application: Suitable for switching a variety of loads, including motors, lighting systems, and heaters.
• Space-Saving Design: The compact Size 0 form factor allows for efficient use of space in control cabinets.
• Enhanced Control Capabilities: Integrated 1 NO and 1 NC auxiliary contacts simplify the design of complex control circuits and provide feedback on the contactor’s status.
• Easy and Secure Installation: Screw terminals offer a simple and robust method for connecting wires, ensuring a secure electrical connection.
• Long Service Life: Built with high-quality materials to withstand frequent switching cycles and a long operational life.

Technical Specifications & Features

• Product Number: 3TB4022-0XK1
• Manufacturer: Siemens
• Product Type: AC Contactor
• Control Voltage: 120 V AC, 60 Hz
• Rated Operational Current (AC-3): 9 A at 400 V
• Rated Power (AC-3): 4 kW at 400 V
• Auxiliary Contacts: 1 NO + 1 NC (1 Normally Open, 1 Normally Closed)
• Frame Size: Size 0
• Connection Type: Screw Connection
• Mounting: Standard DIN rail or screw mounting
• Operating Temperature: Suitable for a wide range of industrial temperatures.

Function

The Siemens 3TB4022-0XK1 contactor’s primary function is to act as an electrically operated switch. When a 120V AC, 60 Hz signal is applied to its coil, the internal mechanism closes the main contacts, allowing power to flow to the connected load. Simultaneously, the auxiliary contacts change state—the NO contact closes and the NC contact opens—to provide feedback or control signals to other parts of the system. This makes it an indispensable component for automating the control of motors and other high-current devices.

Application

• Motor Control Circuits
• Lighting Control Systems
• HVAC Systems
• Pump and Fan Control
• Industrial Machinery and Automation
• Heater Control
