Siemens 3TB4022-0XP1 Contactor 240V AC, 9A, 4kW, Size 0 Original Brand New

Overview

The Siemens 3TB4022-0XP1 contactor is a core component for switching and controlling electric motors. Part of the trusted Siemens 3TB series, this contactor is built for durability and precision. Its compact Size 0 form factor makes it suitable for integration into a wide range of control panels and systems where space is a consideration. The robust design ensures a long service life and consistent performance under demanding conditions.

Key Features & Specification

• Product Number: 3TB4022-0XP1
• Manufacturer: Siemens
• Series: 3TB
• Rated Voltage (Coil): 240V AC, 60 Hz
• Current Rating (AC-3): 9A at 400V
• Power Rating: 4kW at 400V
• Auxiliary Contacts: 1 Normally Open (NO) + 1 Normally Closed (NC)
• Frame Size: Size 0
• Connection Type: Screw terminals
• Standards: IEC, VDE, UL, CSA (confirm with datasheet)
• Applications: Motor starting, switching, and control for industrial machinery.

Benefit

• Reliable Performance: Siemens quality ensures consistent and dependable switching operations, minimizing downtime.
• Space-Saving Design: The Size 0 frame is compact, allowing for efficient use of panel space.
• Integrated Auxiliary Contacts: The built-in 1 NO and 1 NC contacts provide immediate feedback for control circuits, simplifying wiring and reducing the need for separate contact blocks.
• Easy Installation: The screw connection terminals provide a secure and straightforward method for wiring, saving time during setup.
• Versatile Application: Suitable for a wide variety of industrial motor control tasks, from simple on/off switching to complex automation systems.
• Global Recognition: Siemens is a globally recognized and trusted brand, ensuring compatibility and support.

Function

The Siemens 3TB4022-0XP1 contactor functions as an electrically operated switch. When the 240V AC control voltage is applied to the coil, it generates a magnetic field that closes the main power contacts. This allows power to flow to the connected motor. When the voltage is removed, a spring forces the contacts open, interrupting the power. The auxiliary contacts change state simultaneously, providing signals to the control system to indicate the contactor’s status (e.g., motor is running or stopped).
