Siemens 3TB4222-0XC1 Contactor 24V AC, 16A, 7.5kW, 1NO+1NC, Screw Terminal Original Brand New

Overview

The Siemens 3TB4222-0XC1 is a high-performance 3-pole AC contactor designed for reliable switching of electrical loads, particularly in motor control applications. This size 1 contactor is engineered for optimal performance in circuits operating at 60 Hz. Its robust design and high-quality construction ensure long-term durability and safety. The unit features a control coil with a 24V AC rating and is capable of handling up to 16 A in an AC-3 utilization category at 400 V, corresponding to a power rating of 7.5 kW. For enhanced functionality and integration into control systems, it comes equipped with one normally open (1 NO) and one normally closed (1 NC) auxiliary contact. The screw connection terminals provide a secure and straightforward method for wiring.

Benefit

• Reliable Performance: Engineered by Siemens, a leader in industrial automation, this contactor offers consistent and dependable switching performance for demanding applications.
• Versatile Application: Suitable for a wide range of uses, including motor control, lighting circuits, and heating systems.
• Integrated Auxiliary Contacts: The built-in 1 NO and 1 NC auxiliary contacts simplify wiring for signaling and interlocking functions, reducing the need for additional components.
• Easy Installation: The size 1 form factor and screw terminals make for a simple and secure installation process.
• Durability: Constructed with high-quality materials to withstand the rigors of industrial environments and ensure a long service life.

Function

The Siemens 3TB4222-0XC1 acts as an electrically controlled switch used for switching a power circuit. When the 24V AC coil is energized, it creates a magnetic field that closes the main contacts, allowing power to flow to the connected load (e.g., a motor). Simultaneously, the auxiliary contacts change state, providing feedback to the control system. When the coil is de-energized, a spring-loaded mechanism opens the main contacts, interrupting the power flow. This mechanism is crucial for the safe and automated control of high-current devices.

Application

• Motor Starters
• Control Panels
• HVAC Systems
• Industrial Machinery
• Pump Control
• Lighting Circuits
