Siemens 3TB4422-0XB0 Contactor 24V AC, 32A, 15kW, 1NO+1NC, Size 2 Original Brand New

Overview

The Siemens 3TB4422-0XB0 is a high-performance 3-pole AC contactor designed for reliable switching of electrical loads in industrial applications. This robust device features a 24V AC coil for control, making it suitable for a wide range of control circuits. With a rated operational current of 32A and a power rating of 15kW at 400V (AC3), it is an ideal choice for controlling motors and other resistive loads. The contactor is equipped with a standard set of auxiliary contacts (1 normally open (NO) and 1 normally closed (NC)), providing essential feedback and control logic capabilities. Its compact Size 2 frame and secure screw connections ensure easy and dependable installation.

Key Features & Technical Specification

• Product Number: 3TB4422-0XB0
• Type: 3-Pole Contactor
• Operating Frequency: 50 Hz
• Coil Voltage: 24V AC
• Operational Current (AC3): 32A at 400V
• Power Rating (AC3): 15kW at 400V
• Auxiliary Contacts: 1 NO (Normally Open) + 1 NC (Normally Closed)
• Size: Size 2
• Connection Type: Screw Terminals
• Series: Siemens 3TB44

Benefit

• Reliable Performance: Engineered by Siemens, a global leader in industrial automation, this contactor offers consistent and long-lasting performance.
• Enhanced Safety: The integrated auxiliary contacts allow for crucial control loop feedback and interlocking, improving the overall safety of your system.
• Versatile Application: Suitable for a wide range of applications including motor control, lighting circuits, and heating systems.
• Easy Installation: Features clear markings and standard screw terminals for a straightforward and secure setup.
• Durable Design: Built to withstand demanding industrial environments, ensuring a long service life.

Function

The Siemens 3TB4422-0XB0 contactor’s primary function is to act as an electrically operated switch. When the 24V AC control voltage is applied to the coil, it closes the main power contacts, allowing current to flow to the connected load. When the voltage is removed, the contacts open, interrupting the power. The auxiliary contacts change state simultaneously with the main contacts, providing a signal that can be used for control, monitoring, or interlocking purposes within a control circuit.
