Siemens 3TB4422-0XG0 Contactor 36V AC Coil, 32A, 15kW, 1NO+1NC Auxiliary Contact, Size 2 Original Brand New

Overview

The Siemens 3TB4422-0XG0 is a robust and reliable AC contactor designed for industrial control applications, particularly for switching and controlling motors. Part of the trusted Siemens 3TB series, this contactor is engineered to handle demanding electrical loads with superior performance and durability. Its compact size and convenient screw connection terminals make it easy to install and integrate into new or existing control panels.

Key Features & Technical Specification

• Product Number: Siemens 3TB4422-0XG0
• Contactor Type: AC Contactor
• Coil Voltage: 36V AC, 50 Hz
• Rated Operational Current (AC-3): 32 A at 400V
• Rated Operational Power (AC-3): 15 kW at 400V
• Auxiliary Contacts: 1 Normally Open (NO) + 1 Normally Closed (NC)
• Frame Size: Size 2
• Connection Type: Screw Connection Terminals
• Typical Applications: Switching and controlling AC motors, lighting systems, heating circuits, and other resistive loads.

Benefit

• High Reliability: Manufactured by Siemens, a global leader in industrial automation, ensuring high-quality construction and long-term operational reliability.
• Efficient Performance: Optimized for 50 Hz AC systems, delivering consistent and efficient switching performance for a wide range of motor and load types.
• Safety & Control: The integrated 1 NO and 1 NC auxiliary contacts provide essential feedback and control options for interlocking, status indication, and complex control circuits.
• Easy Installation: Features clearly marked screw terminals, simplifying wiring and reducing installation time and effort.
• Versatile Use: Suitable for a variety of industrial environments and applications, from simple motor starts to complex automated processes.

Function

The Siemens 3TB4422-0XG0 functions as an electrically controlled switch used for power circuits. When the 36V AC coil is energized, it generates a magnetic field that pulls the main contacts together, allowing high-power current to flow through the device to a connected load, such as an electric motor. When the coil is de-energized, the contacts spring open, safely interrupting the power flow. The auxiliary contacts switch simultaneously with the main contacts, providing signals for control and monitoring systems.

Application

• Motor control and starting in industrial machinery
• HVAC systems and pumps
• Conveyor systems
• Compressors
• Lifting and hoisting equipment
• Lighting control systems
• Industrial automation and control panels
