A premium, touch-safe pin busbar designed for reliable and efficient power distribution in 3-phase miniature circuit breaker (MCB) installations. Featuring a 16 mm² copper cross-section and a 214 mm length, this busbar is cut-to-length compatible, offering ultimate flexibility for custom panel configurations. It comes complete with end caps for safety and insulation. Part of the SENTRON series, it is rated for up to 80A.
The Siemens 5ST3708 is a high-quality pin busbar designed for safe and reliable electrical connections in 3-phase systems. Featuring a touch-safe design and a 16 mm² cross-section, this busbar is ideal for professional electrical installations and distribution systems. At 214 mm in length, it can be easily cut to suit your specific needs, and includes end caps for added safety.
Enhanced Safety (Touch-Safe): The fully insulated design provides a high level of touch-safe protection, reducing the risk of accidental contact and electrical hazards during installation and maintenance.
Time-Saving Installation: Simplifies the connection of multiple circuit breakers compared to traditional cable wiring, dramatically cutting down on wiring time and labor costs.
Customizable Length: The cut-to-length feature allows you to adapt the busbar precisely to the number of poles required, minimizing waste and ensuring a professional, clean installation.
High Conductivity: Constructed with high-quality copper 16 mm for excellent electrical conductivity and minimal power loss.
System Reliability: Provides a secure, vibration-resistant, and permanent connection, improving the overall reliability and performance of your electrical panel.
3-phase electrical busbar for efficient power distribution
Cuttable length to fit various electrical panels
Touch-safe to prevent accidental electrical contact
Suitable for commercial and industrial electrical applications
Includes protective end caps for enhanced safety
Visit 5ST3708 for more detail info
For more our products visit turll
| SKU / Model | 5ST3708 |
|---|---|
| Brand | SIEMENS |
| product brand name | SENTRON |
| product designation | Pin busbar |
| design of the product | 16 mm², 3PH L214mm |
| phase number | 3 |
| cross-section | 16 mm² |
| operational current / rated value | 80Â A |
| product feature / insulated | Yes |
| type of electrical connection | Pin |
| length | 214Â mm |
| Weight | 0.118 kg |
| Dimensions | 100.00 × 220.00 × 110.00 mm |
