Siemens 5SV6016-7KK25 AFDD-MCB Combination 230V, 6kA, 1+N C-Curve, 25A Compact (1MW) Original Brand New
$136.18
Siemens AFDD-MCB combination device, offering comprehensive fire and circuit protection in a single, ultra-compact 1-module (1MW) width. Rated at 25A with a C-curve and 6kA short-circuit capacity, it provides reliable defense against parallel, serial, and residual current arc faults, along with traditional overload and short-circuit protection for modern electrical installations.
Availability: In stock
Overview
The Siemens 5SV6016-7KK25 AFDD-MCB Combination is an advanced electrical protection device designed to enhance safety in low-voltage installations. It combines Arc Fault Detection Device (AFDD) and Miniature Circuit Breaker (MCB) technology into a single compact unit, offering reliable protection against arc faults, overloads, and short circuits.
Engineered for 230V systems, this device features a 6kA breaking capacity, 1+N pole configuration, C-curve tripping characteristic, and a 25A rated current, making it ideal for modern residential and commercial applications where fire prevention and circuit protection are critical.
Benefit
-
Enhanced Fire Protection – Detects dangerous arc faults that conventional breakers may miss
-
Integrated Safety Solution – Combines AFDD and MCB in one compact device
-
Space-Saving Design – Compact 1MW width for efficient distribution board layout
-
Reliable Performance – Suitable for residential and light commercial installations
-
Trusted Siemens Quality – Engineered to meet high safety and performance standards
Function
-
Detects and interrupts series and parallel arc faults
-
Provides overload and short-circuit protection
-
Automatically disconnects power during hazardous electrical conditions
-
Ensures compliance with modern electrical safety requirements
-
Supports stable and safe operation of electrical circuits
Technical Highlight
-
Product Number: 5SV6016-7KK25
-
Voltage: 230V
-
Breaking Capacity: 6kA
-
Poles: 1+N
-
Tripping Curve: C
-
Rated Current: 25A
-
Design: Compact (1MW)
-
Type: AFDD-MCB Combination
Visit 5SV6016-7KK25 for more detail info
For more our products visit turll
Download
| Weight | 0.139 kg |
|---|---|
| Dimensions | 80.00 × 100.00 × 44.00 mm |
| Brand | SIEMENS |
| product brand name | SENTRON |
| product designation | Arc-fault detection unit MCB |
| design of the product | Compact unit |
| number of poles | 2 |
| design of pole | 1P+N |
| tripping characteristic class | C |
| size of installation devices / acc. to DIN 43880 | 1 |
| touch protection against electrical shock / acc. to EN 50274 | finger and back-of-hand safe |
| mechanical service life (switching cycles) / typical | 10 000 |
| switching function / short-term delayed | No |
| overvoltage category | III |
| degree of pollution | 2 |
| type of voltage / of the operating voltage | AC |
| supply voltage | – |
| ● at AC / rated value | 230 V |
| value range / of the supply voltage frequency | 50Hz |
| protection class IP | IP20, with connected protective device and conductors |
| switching capacity current | – |
| ● according to EN 60898-1 / rated value | 6 000 A |
| ● acc. to IEC 60947-2 / rated value | 6 000 A |
| power loss [W] / for rated value of the current / at AC / in hot operating state / per pole | 2.22 W |
| tripping current | – |
| ● in the event of electrical arcs in parallel with the load / minimum | 50 A |
| ● in the event of electrical arcs in parallel with the load / maximum | 500 A |
| ● in the event of electrical arcs in series with the load / minimum | 2 A |
| ● in the event of electrical arcs in series with the load / maximum | 25 A |
| operational current / at AC / rated value | 25 A |
| product feature | – |
| ● halogen-free | Yes |
| ● silicon-free | Yes |
| product extension / installable / supplementary devices | Yes |
| connectable conductor cross-section / solid | – |
| connectable conductor cross-section / stranded | – |
| connectable conductor cross-section / finely stranded / with core end processing | – |
| tightening torque / with screw-type terminals | – |
| position / of power supply cord | any |
| installation depth | 70 mm |
| number of modular width units | 1 |
| fastening method | DIN rail (REG) |
| mounting position | any |
| ambient temperature / during operation | – |
| ambient temperature / during storage | – |
| ● minimum | -40 °C |
| ● maximum | 75 °C |
| ambient temperature / with relative humidity 95% | 55 °C |
| number of test cycles / for environmental testing / acc. to IEC 60068-2-30 | 28 |
