Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A
Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A
Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A
Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A
Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A
Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A

SIEMENS

Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital Output Module, DQ 8x, 24V DC, 0.5A Original Brand New

Model / SKU6ES7132-6BF01-0BA0

SIMATIC ET 200SP digital output module with 8 outputs, 24V DC, 0.5A standard, PNP source output, featuring advanced diagnostics and high reliability for industrial automation systems.

Original price was: $113.23.Current price is: $56.71.
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 6ES7132-6BF01-0BA0 is a SIMATIC ET 200SP Digital Output Module designed for efficient and reliable control in industrial automation environments. This module provides 8 digital outputs operating at 24V DC with 0.5A per channel, using PNP (P-switching) source outputs.

Engineered to fit Base Unit type A0, this compact module supports seamless integration into ET 200SP distributed I/O systems. It includes advanced diagnostics and substitute value output functions to ensure operational continuity and system safety.

Benefit

  • Space-Saving Design: Part of the compact ET 200SP series, reducing control cabinet footprint.

  • Enhanced Reliability: Built-in diagnostics reduce downtime by identifying wiring faults immediately.

  • Simple Installation: Tool-free wiring with Push-in terminals when used with the appropriate BaseUnit (Type A0).

  • Easy Identification: Uses Color Code CC02 for quick visual verification during maintenance.

Function & Features

  • Digital Outputs: 8x 24V DC, 0.5A

  • Output Type: Source output (PNP, P-switching)

  • Diagnostics Functions:

    • Short-circuit to L+

    • Short-circuit to ground

    • Wire break detection

    • Supply voltage monitoring

  • Substitute Value Output: Ensures safe operation during faults

  • Color Code: CC02

  • Base Unit Compatibility: BU-type A0

  • Packing Unit: 1 piece

Technical Specification

  • Manufacturer: Siemens

  • Product Number: 6ES7132-6BF01-0BA0

  • Series: SIMATIC ET 200SP

  • Module Type: Digital Output Module

  • Voltage Rating: 24V DC

  • Current Rating: 0.5A per channel

  • Number of Outputs: 8

Application

  • Industrial automation systems

  • Manufacturing and process control

  • Machine control panels

  • Distributed I/O systems

  • Factory automation solutions

Download

Datasheet in PDF

Visit 6ES7132-6BF01-0BA0 for more detail info

For more our products visit turll



Specifications

SKU / Model6ES7132-6BF01-0BA0
BrandSIEMENS
Product type designationDQ 8x24VDC/0.5A ST
HW functional statusFrom FS02
Firmware versionV0.0
● FW update possibleNo
usable BaseUnitsBU type A0
Color code for module-specific color identification plateCC02
● I&M dataYes; I&M0 to I&M3
● Isochronous modeNo
● STEP 7 TIA Portal configurable/integrated from versionV14
● STEP 7 configurable/integrated from versionV5.5 SP3 or higher
● PCS 7 configurable/integrated from versionV8.1 SP1
● PROFIBUS from GSD version/GSD revisionOne GSD file each, Revision 3 and 5 and higher
● PROFINET from GSD version/GSD revisionGSDML V2.3
● DQYes
● DQ with energy-saving functionNo
● PWMNo
● OversamplingNo
● MSONo
permissible range, lower limit (DC)19.2 V
permissible range, upper limit (DC)28.8 V
Reverse polarity protectionYes
Current consumption, max.35 mA; without load
Rated value (DC)24 V
Power loss, typ.1 W
● Address space per module, max.1 byte; + 1 byte for QI information
Automatic encodingYes
● Mechanical coding elementYes
● Type of mechanical coding elementType A
● 1-wire connectionBU type A0
● 2-wire connectionBU type A0
● 3-wire connectionBU type A0 with AUX terminals or potential distributor module
● 4-wire connectionBU type A0 + Potential distributor module
Type of digital outputSource output (PNP, current-sourcing)
Number of digital outputs8
Current-sourcingYes
Digital outputs, parameterizableYes
Short-circuit protectionYes
● Response threshold, typ.1 A
Limitation of inductive shutdown voltage toTyp. L+ (-50 V)
Controlling a digital inputYes
● lower limit48 Ω
● upper limit12 kΩ
● for signal "1", min.L+ (-0.8 V)
● for signal "1" rated value0.5 A
● for signal "1" permissible range, max.0.5 A
● for signal "0" residual current, max.0.1 mA
● "0" to "1", max.50 µs; at rated load
● "1" to "0", max.100 µs; at rated load
● for upratingNo
● for redundant control of a loadYes
● with resistive load, max.100 Hz
● with inductive load, max.2 Hz
● on lamp load, max.10 Hz
● Current per channel, max.0.5 A
● Current per module, max.4 A
— up to 60 °C, max.4 A
— up to 50 °C, max.4 A
● shielded, max.1 000 m
● unshielded, max.600 m
Diagnostics functionYes
Substitute values connectableYes
● Diagnostic alarmYes
● Monitoring the supply voltageYes
● Wire-breakYes; Module-wise
● Short-circuit to MYes; Module-wise
● Short-circuit to L+Yes; Module-wise
● Group errorYes
● Monitoring of the supply voltage (PWR-LED)Yes; green PWR LED
● Channel status displayYes; green LED
● for channel diagnosticsNo
● for module diagnosticsYes; green/red DIAG LED
● between the channelsNo
● between the channels and backplane busYes
● between the channels and the power supply of the electronicsNo
Isolation tested with707 V DC (type test)
Suitable for safety functionsNo
Suitable for safety-related tripping of standard modulesYes; see FAQ Entry ID: 39198632
● Performance level according to ISO 13849-1PL d
● SIL acc. to IEC 61508SIL 2
● horizontal installation, min.-30 °C; < 0 °C as of FS02
● horizontal installation, max.60 °C
● vertical installation, min.-30 °C; < 0 °C as of FS02
● vertical installation, max.50 °C
● Installation altitude above sea level, max.5 000 m; Restrictions for installation altitudes > 2 000 m, see manual
Width15 mm
Height73 mm
Depth58 mm
Weight, approx.30 g
last modified:9/27/2021
Product ConditionBrand New, New - Backlog, New - No Original Box, New - Original Box Opened, Used - Average, Used - Below Average, Used - Excellent, Used - Fairly Good, Used - Good, Used - Poor, Used - Very Good
Weight0.035 kg
Dimensions6.50 × 7.80 × 2.30 mm
