1FK2104-4AF00-2MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-4AF00-2MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-4AF00-2MB0 SIMOTICS S-1FK2 HD servo motor is a high-performance synchronous motor engineered for precision, durability, and efficiency. With a rated torque of 1.27 Nm and a rated power output of 0.4 kW at 3000 rpm (380–480 V), or 0.2 kW at 1500 rpm (200–240 V), this model provides reliable operation across a wide voltage range. The motor comes with IP64 protection, ensuring resilience against dust and splashes, while the cylindrical shaft design (D14 x 30 mm) supports robust mechanical integration. Featuring an absolute encoder AM22DQC with 22-bit single-turn and 12-bit multi-turn resolution, the motor guarantees accurate positioning and seamless feedback for demanding automation applications.

Equipped with a DRIVE-CLiQ plug M17 and a compact power connector, this motor offers simple connection and integration into automation systems. Its compact construction and dynamic response make it a versatile choice for motion control tasks requiring precision and long-term reliability.

Overview

The SIMOTICS S-1FK2 servo motor family is designed for dynamic performance and compact installation. These motors are widely used in industrial applications that demand precision, stability, and high overload capacity. With a streamlined range of options, the S-1FK2 series ensures straightforward selection and fast commissioning. They form the foundation of the SINAMICS S210 servo drive system, creating a powerful solution for drive technology requirements.

For applications requiring extended functionality, the SIMOTICS 1FT2 motors complement the 1FK2 line. They feature additional torque ranges, more refined speed levels, and flexible configuration options. Together, the 1FK2 and 1FT2 families provide versatile drive solutions for industries with diverse automation challenges.

SIMOTICS S-1FK2 Highlights

• High Dynamic motors: optimized for applications with low moving masses, offering rapid acceleration and responsiveness.
• Compact motors: designed for stable and precise control where medium to high inertial loads must be moved with accuracy.

Download

Data Sheet (PDF)

Product Code: 1FK2104-4AF00-2MB0
