1FK2104-5AF11-0SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-5AF11-0SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-5AF11-0SA0 SIMOTICS S-1FK2 High Dynamic servo motor is designed to provide exceptional performance, precision, and efficiency for industrial automation. This synchronous motor delivers a torque of 2.4 Nm with rated power of 0.75 kW at 3000 rpm (380–480 V) and 0.375 kW at 1500 rpm (200–240 V). Built with a reliable holding brake, IP65 degree of protection, and a cylindrical shaft measuring 19×40 mm, it offers robust operation and long-term durability in demanding environments.

Featuring a single-turn 22-bit absolute encoder (AS22DQC) and OCC interface with a rotatable M17 plug, this motor ensures high-resolution feedback and flexible integration within automation systems. Its compact structure combined with high power density makes it particularly well-suited for machine tools, packaging equipment, material handling, and robotics where fast and accurate motion control is essential.

Overview

The SIMOTICS S-1FK2 servomotor family is widely recognized for its reliability, overload capability, and optimized design. These motors are central to the SINAMICS S210 drive system, delivering both compact construction and superior dynamic response. They address a broad spectrum of applications requiring either highly dynamic low-inertia motion or stable performance with medium inertia loads.

For applications requiring extended versatility, the 1FT2 motor series expands the portfolio by offering finer speed ranges, increased torque levels, and multiple configuration options. This allows precise adaptation to challenging drive tasks, even under demanding industrial conditions.

Download

Data Sheet (PDF)

Product Code: 1FK2104-5AF11-0SA0
