1FK2204-6AF11-0SA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

1FK2204-6AF11-0SA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

The SIEMENS 1FK2204-6AF11-0SA0 belongs to the SIMOTICS S-1FK2 series of compact synchronous servo motors, designed to deliver outstanding performance, durability, and flexibility for modern automation systems. With a rated torque of 3.2 Nm and nominal power output of 1 kW at 3000 rpm (380–480 V), this motor ensures efficient and reliable operation even in challenging environments. At lower voltage ranges of 200–240 V, it provides 0.5 kW at 1500 rpm, making it a versatile solution for varied applications. The model is equipped with a holding brake, cylindrical shaft (D19x40mm), and a high-resolution absolute encoder (AS22DQC, 22-bit, single-turn), which guarantees precision, stable control, and smooth integration into automation systems.

Its IP65 protection class ensures resistance against dust and water jets, making it suitable for harsh industrial conditions. The motor is supplied with an OCC interface and rotatable M17 connector for flexible installation. By combining compact dimensions with a robust design, this motor addresses essential requirements in servo drive technology while maintaining high energy efficiency.

Overview

SIMOTICS S-1FK2 motors are compact, dynamic, and versatile. They are engineered to provide high power density, overload capability, and excellent operational stability. This product line is optimized for seamless integration with SINAMICS S210 drive systems, enabling efficient machine concepts in industries such as packaging, robotics, handling, and general automation.

The product family also includes the SIMOTICS S-1FT2 motors, an extended series offering additional torque levels, fine speed gradings, and a wider range of configurations. Together, these motors provide tailored solutions for simple as well as complex automation challenges. High-Dynamic variants are optimized for low-inertia systems requiring fast acceleration, while Compact versions are designed for medium inertia loads with stable control performance.

Download

Data Sheet (PDF)

Product Code: 1FK2204-6AF11-0SA0
