1FK7032-2AK71-1CH1-ZJ13 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1CH1-ZJ13 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1CH1-ZJ13 belongs to the advanced SIMOTICS S-1FK7 series, representing the next generation of compact permanent-magnet synchronous motors. Designed for precision, performance, and flexibility, this motor delivers 0.5 kW nominal power at 600 V DC with a rated torque of 1.15 Nm at 6000 rpm. It features a naturally cooled IMB 5 design with a rotatable power connector, smooth shaft with tolerance N, and a high-resolution 24-bit absolute encoder combined with a 12-bit multi-turn encoder through the DRIVE-CLiQ interface.

Integrated with a holding brake and IP65 protection, this motor ensures durability in demanding industrial environments. In addition, this configuration comes with the J13 option, which includes an ALPHA SP+ SP 060S-MF2 planetary gearing, two stages, ratio I=20, complete with feather key connection.

The SIMOTICS S-1FK7 series is well-known for its adaptability. With a wide selection of encoders and gear options, the motors can be tailored to virtually any industrial application. They are designed for direct operation without external cooling, utilizing their surface for effective heat dissipation. The high overload capacity and consistent efficiency make them ideal for long-term reliability.

Overview

• Compact permanent-magnet synchronous motors with modular options
• Flexible encoder systems for speed and position control
• Can be combined with SINAMICS S120/S220 drive systems
• High overload capability with efficient surface cooling

Benefits

• Space-saving design with excellent power density
• Universal adaptability across a wide range of industries
• High dynamic response with low rotor inertia (HD motors)
• Stable performance for high or variable load inertia (HI motors)
• Minimal commissioning overhead and quick disturbance compensation

Application

• Machine tools, robots, and handling systems
• Wood, glass, ceramics, and stone working equipment
• Packaging, plastics, and textile machinery
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1CH1-ZJ13
