1FK7032-2AK71-1RH1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1RH1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RH1-ZJ09 SIMOTICS S synchronous motor is a premium industrial solution engineered for precision, durability, and reliability. With a power rating of 0.5 kW, rated torque of 1.15 Nm at 6000 rpm, and natural cooling, this compact motor is designed to deliver consistent performance under demanding conditions. It comes with a rotatable flange power connector, an absolute encoder AM20DQI with DRIVE-CLiQ interface, smooth shaft, holding brake, and IP65 degree of protection. The integrated planetary gearing ALPHA SP+ 060S-MF1 with a single stage and gear ratio of 10 provides excellent torque transmission for applications requiring high efficiency and smooth operation.

SIMOTICS S-1FK7 motors are known for their adaptability across industries. Their modular concept allows for easy combination with different encoders and gearboxes, ensuring flexibility in design and application. When paired with SINAMICS S120 or S220 drive systems, they form a complete drive solution with advanced control capabilities, outstanding precision, and efficient energy use. Heat dissipation through the motor surface eliminates the need for external cooling, simplifying installation and reducing maintenance.

Overview

• Compact permanent-magnet synchronous motors with high power density
• Flexible encoder and gearbox options for multiple applications
• Excellent dynamic response and robust overload capacity
• Reliable closed-loop control for variable load demands
• Designed for long service life with minimal commissioning effort

Benefits

• Space-saving installation in automation systems
• Outstanding adaptability for machine tools, robotics, and packaging
• High accuracy and stable control even in challenging operations
• Wide product range suitable for diverse industries

Applications

• Machine tools and robotics
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing and auxiliary axis drives

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RH1-ZJ09
