1FK7032-2AK71-1RH1-ZJ17 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7032-2AK71-1RH1-ZJ17 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RH1-ZJ17 SIMOTICS S-1FK7 is a compact, high-performance synchronous motor designed for advanced industrial applications. With a rated power of 0.5 kW, maximum speed of 6000 rpm, and a torque of 1.15 Nm, this motor delivers reliable performance in a naturally cooled IMB 5 design. The flange 1 power connector is rotatable for flexible installation, while the integrated absolute encoder (20-bit + 12-bit multi-turn with DRIVE-CLiQ interface) ensures precise position and speed control. Equipped with a holding brake and feather key, this motor is robust, durable, and optimized for high-precision operation.

Built for universal applications, the SIMOTICS S-1FK7 motors can be combined with SINAMICS S120/S220 drive systems to create high-functionality, integrated automation solutions. The motor dissipates heat efficiently through its surface, eliminating the need for external cooling, and provides high overload capability to handle demanding industrial environments. The J17 variant features an ALPHA SP+ planetary gearing system with two stages and a 50:1 ratio, delivering smooth, accurate mechanical performance across a range of tasks.

Overview

SIMOTICS S-1FK7 motors are engineered to satisfy the stringent requirements of modern machinery. The compact design allows for space-saving installation without compromising performance. Available with various gearboxes and encoders, these motors adapt easily to diverse applications. Their low rotor inertia ensures high dynamic response, while high-inertia variants provide robust closed-loop control for variable loads. This flexibility reduces commissioning time and simplifies disturbance compensation.

Application

• Machine tools and CNC machinery
• Robotics and automated handling systems
• Processing machinery for wood, glass, ceramics, and stone
• Packaging, plastics, and textile machines
• Printing machinery and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RH1-ZJ17
