1FK7033-4CK71-1CG1 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7033-4CK71-1CG1 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CK71-1CG1 SIMOTICS S-1FK7 synchronous motor is a high-performance drive solution built for precision, efficiency, and reliability in industrial automation. Delivering a nominal power of 0.57 kW and a torque of 1.3 Nm at 6000 rpm, this motor achieves outstanding dynamic response and operational stability. Its compact, naturally cooled design ensures effective heat dissipation through the motor housing, eliminating the need for external cooling while maintaining continuous performance. With an IP65 protection rating, it is engineered for durability in demanding industrial conditions.

The motor features an absolute encoder with 24-bit single-turn and 12-bit multi-turn resolution connected through a DRIVE-CLiQ interface (encoder AM24DQI). This configuration guarantees precise position and speed feedback, making it ideal for integration with SINAMICS S120 or S220 drive systems. The smooth plain shaft with tolerance N, rotatable power connector, and IMB 5 mounting design provide flexibility and ease of installation in compact machine layouts. The absence of a holding brake allows optimized operation in dynamic motion control environments.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for diverse automation tasks. Their wide selection of variants, optional gearboxes, and encoder systems enable perfect adaptation to specific applications. When combined with SIEMENS drive systems, they form a robust and efficient motion control solution that meets the requirements of modern machine design.

Benefits & Applications

• Compact build with high power density for space-efficient installation
• Exceptional performance in high-speed and high-precision environments
• Flexible configuration for industrial automation and robotics
• Reduced commissioning time with optimized closed-loop control
• Applicable in machine tools, handling systems, packaging, and printing
• Reliable operation in wood, glass, plastics, ceramics, and textile machinery

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1CG1
