1FK7033-4CK71-1CH0-ZV40 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor with Gearbox Original Brand New

1FK7033-4CK71-1CH0-ZV40 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor with Gearbox Original Brand New

The SIEMENS 1FK7033-4CK71-1CH0-ZV40 SIMOTICS S-1FK7 synchronous motor is an advanced high-performance drive component engineered for precision, durability, and versatility in modern automation systems. With a rated power output of 0.57 kW and a nominal torque of 1.3 Nm at 6000 rpm, this permanent-magnet motor delivers efficient, stable, and consistent operation under continuous load. Its naturally cooled IMB 5 frame design allows for efficient heat dissipation through the motor surface, ensuring long-lasting reliability even in demanding industrial environments.

Equipped with an integrated 24-bit absolute encoder combined with a 12-bit multiturn system via the DRIVE-CLiQ interface, this motor provides precise speed and position control suitable for complex motion applications. The plain shaft with tolerance N and the addition of a holding brake ensure superior mechanical integrity. The power connector is rotatable, allowing flexible installation and simplified cabling in tight spaces. Rated with IP64 protection, the motor offers robust resistance to dust and splash water, ideal for industrial settings requiring endurance and safety.

This exclusive motor configuration includes an ALPHA LP+ LP 070-MO1 one-stage planetary gearbox (ratio i = 5) with a fitted key, offering enhanced torque output and smooth power transmission for high-precision applications.

Overview

The SIMOTICS S-1FK7 series motors are compact, permanent-magnet synchronous units optimized for performance and adaptability. They can be paired with SINAMICS S120 or S220 drive systems to form a powerful automation solution. With flexible encoder and gearbox options, the series supports a wide range of industrial applications requiring high dynamics, smooth control, and operational precision.

Benefits & Applications

• High power density enabling compact and space-efficient installation
• Excellent dynamic response and control precision
• Robust construction for continuous industrial operation
• Flexible integration with SINAMICS drive systems
• Ideal for machine tools, robotics, packaging, printing, and textile machinery
• Available with optional gearboxes and encoder variants for customized solutions

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1CH0-ZV40
