1FK7040-2AK71-1FB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,218.55
The SIEMENS SIMOTICS S 1FK7040-2AK71-1FB2 is a compact, high-precision synchronous motor delivering 0.69 kW and 1.6 Nm torque. Engineered for reliability, it features an integrated encoder, IP65 protection, rotatable power connector, and a holding brake — ideal for advanced automation and precision motion systems.
1FK7040-2AK71-1FB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7040-2AK71-1FB2 is a high-quality synchronous servo motor engineered for precision, reliability, and outstanding performance in industrial automation. This compact motor delivers an impressive power output of 0.69 kW at a nominal speed of 6000 rpm, with a rated torque of 1.6 Nm (100K). Designed with a 600V DC supply and natural cooling, the unit ensures efficient thermal management and dependable operation even under demanding conditions. The integrated 22-bit + 12-bit multiturn absolute encoder (AM22DQ) with DRIVE-CLiQ interface enables precise position and speed feedback, ensuring seamless integration with SIEMENS SINAMICS drive systems.
Built with a robust IP65 housing (and IP67 at the DE flange), the 1FK7040-2AK71-1FB2 motor is resistant to dust, moisture, and industrial contaminants, guaranteeing long service life. The rotatable power connector and fitted-key shaft provide easy installation and mechanical compatibility across a wide range of machines. The motor also includes a holding brake for secure position control during power-off conditions, making it an ideal solution for precision-driven environments that demand accuracy and consistency.
Overview
The SIMOTICS S-1FK7 motor series from SIEMENS is designed to offer maximum flexibility for modern automation systems. These permanent-magnet synchronous motors can be perfectly adapted to any industrial application through various encoder options, gearboxes, and configurations. When combined with the SINAMICS S120 or S220 drive systems, they form a high-performance, intelligent motion control solution capable of meeting the rigorous demands of next-generation manufacturing technologies.
Benefits
- Compact construction with high power density for space-efficient installation.
- Compatible with a wide range of machine types and applications.
- Exceptional dynamic response due to low rotor inertia.
- Durable closed-loop control for stable performance under variable loads.
- Easy configuration and commissioning with minimal optimization required.
Applications
- Machine tools and automation systems
- Robotic and handling equipment
- Wood, glass, ceramics, and stone processing machines
- Packaging, plastic, textile, and printing machinery
- Auxiliary or secondary axis control
Download
Product Code: 1FK7040-2AK71-1FB2
More Siemens products at Turll.com
| Weight | 3.5 kg |
|---|
